- Unit Number: 105M12
- Brand: N-Tron
- Role: Industrial Ethernet Switch
- Switch Type: Unmanaged
- Ports: 5
- Communications: 10/100BaseTX Ethernet
- Auto-Negotiation: Yes
- Redundant Power Input: Yes
- Enclosure Protection: IP65/67
- Humidity: 5-100%
- Operating Temperature Range: -40° to 80°C
- Max Altitude: 10,000ft
-
What cable type is required for the Ethernet ports on the 105M12?
- The 105M12 requires at least Cat3 for 10BaseT and Cat5 for 100BaseT.
-
What kind of connectors are used on the 105M12?
- The 105M12 uses M12 4-pin, D-code connectors for the Ethernet ports and an M12 5-pin, A-code port for power input.
-
What input voltage does the 105M12 operate off of?
- The 105M12 is made for 24VDC (10-30V) operation.
⭐⭐⭐⭐⭐ 5.0
The 105M12 has slightly fewer ports than the 108 model, but the main communication features of these switches are the same. The main benefits of the 105M12 compared to the 108 include both greater heat tolerance and a lighter, more compact design. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
105M12 |
Description |
105M12 By Red Lion N-Tron Unmanaged Industrial 5-Port Ethernet Switch New Sealed |
Condition |
New Sealed With 1 Year Warranty. |
Technical Specifications | |
| Unit Number | 105M12 |
| Brand | N-Tron |
| Role | Industrial Ethernet Switch |
| Switch Type | Unmanaged |
| Ports | 5 |
| Communications | 10/100BaseTX Ethernet |
| Auto-Negotiation | Yes |
| Redundant Power Input | Yes |
| Enclosure Protection | IP65/67 |
| Humidity | 5-100% |
| Operating Temperature Range | -40° to 80°C |
| Max Altitude | 10,000ft |
Frequently Asked Questions | |
| What cable type is required for the Ethernet ports on the 105M12? The 105M12 requires at least Cat3 for 10BaseT and Cat5 for 100BaseT. | |
| What kind of connectors are used on the 105M12? The 105M12 uses M12 4-pin, D-code connectors for the Ethernet ports and an M12 5-pin, A-code port for power input. | |
| What input voltage does the 105M12 operate off of? The 105M12 is made for 24VDC (10-30V) operation. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 105M12 has slightly fewer ports than the 108 model, but the main communication features of these switches are the same. The main benefits of the 105M12 compared to the 108 include both greater heat tolerance and a lighter, more compact design. -Automation Industrial Quality Assurance Manager |
|
