- Product Name: 14C10
- OEM: Reliance Electric
- Family: MinPak Plus
- Part Type: DC Controller
- Enclosed: Yes
- Horsepower Range: 0.25-0.75HP
- AC Voltage: 115VAC
- Voltage Phases: 1
- Tolerance: ±10%
- Frequency: 50/60Hz
- Overload Capacity: 1.5% Full Load (1 Min)
- Manual ID: D-3838-6
-
What is the NEMA rating of the enclosure for the 14C10?
- The 14C10 has a NEMA 4/12 type enclosure.
-
What service factor is the 14C10 rated for?
- The 14C10 is rated at a continuous service factor of 1.0.
-
What is the maximum temperature the 14C10 can operate in?
- The 14C10 can operate in conditions up to 40°C.
⭐⭐⭐⭐⭐ 5.0
The 14C10 is one of the enclosed models of MinPak Plus controllers. This enclosure allows it to operate in much more extreme environmental conditions than the chassis-only models. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
14C10 MinPak Plus |
Description |
14C10 By Reliance Electric 115VAC 50/60Hz MinPak Plus Single-Phase DC Controller |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty |
Technical Specifications | |
| Product Name | 14C10 |
| OEM | Reliance Electric |
| Family | MinPak Plus |
| Part Type | DC Controller |
| Enclosed | Yes |
| Horsepower Range | 0.25-0.75HP |
| AC Voltage | 115VAC |
| Voltage Phases | 1 |
| Tolerance | ±10% |
| Frequency | 50/60Hz |
| Overload Capacity | 1.5% Full Load (1 Min) |
| Manual ID | D-3838-6 |
Frequently Asked Questions | |
| What is the NEMA rating of the enclosure for the 14C10? The 14C10 has a NEMA 4/12 type enclosure. | |
| What service factor is the 14C10 rated for? The 14C10 is rated at a continuous service factor of 1.0. | |
| What is the maximum temperature the 14C10 can operate in? The 14C10 can operate in conditions up to 40°C. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 14C10 is one of the enclosed models of MinPak Plus controllers. This enclosure allows it to operate in much more extreme environmental conditions than the chassis-only models. -Automation Industrial Quality Assurance Manager |
|
