- Part ID: 14C40
- Brand: Reliance Electric
- Product Series: MinPak Plus
- Unit Type: Controller
- Enclosure Type: NEMA
- NEMA Rating: Type 4/12
- Minimum Horsepower: 1/4HP
- Maximum Horsepower: 3/4HP
- Nominal Voltage Rating: 115VAC
- DC Armature Voltage: 90VDC
- Average DC Armature Amps: 2.5-7.5A
- Manual Number: D-3838-6
-
How is the 14C40 meant to be mounted?
- The 14C40 can be panel-mounted or wall-mounted.
-
Can a remote station be used with the 14C40?
- Yes, the 14C40 supports the use of a remote operator station.
-
Does the 14C40 keep its NEMA rating with a faceplate installed?
- Yes, the 14C40 maintains its NEMA rating with any properly installed faceplate.
⭐⭐⭐⭐⭐ 5.0
The 14C40 is one of the only 115VAC versions of MinPak Plus controller. This model's enclosure gives it much more flexibility in terms of mounting location than the chassis-style version. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
14C40 MinPak Plus |
Description |
14C40 By Reliance Electric 1-Phase 3/4 HP Regenerative DC Drive MinPak Plus NSNB |
Condition |
New Surplus Open Box With 1 Year Warranty. |
Technical Specifications | |
| Part ID | 14C40 |
| Brand | Reliance Electric |
| Product Series | MinPak Plus |
| Unit Type | Controller |
| Enclosure Type | NEMA |
| NEMA Rating | Type 4/12 |
| Minimum Horsepower | 1/4HP |
| Maximum Horsepower | 3/4HP |
| Nominal Voltage Rating | 115VAC |
| DC Armature Voltage | 90VDC |
| Average DC Armature Amps | 2.5-7.5A |
| Manual Number | D-3838-6 |
Frequently Asked Questions | |
| How is the 14C40 meant to be mounted? The 14C40 can be panel-mounted or wall-mounted. | |
| Can a remote station be used with the 14C40? Yes, the 14C40 supports the use of a remote operator station. | |
| Does the 14C40 keep its NEMA rating with a faceplate installed? Yes, the 14C40 maintains its NEMA rating with any properly installed faceplate. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 14C40 is one of the only 115VAC versions of MinPak Plus controller. This model's enclosure gives it much more flexibility in terms of mounting location than the chassis-style version. -Automation Industrial Quality Assurance Manager |
|
