- Model ID: 1SU21005
- Manufacturer: Reliance Electric
- Product Line: SP500
- Functional Description: AC Drive
- Enclosure Rating: NEMA 1
- Input Voltage: 230VAC
- Power Rating: 5HP
- Operating Temperature: 0° to 40°C
- Storage Temperature: -40° to 65°C
- Manual Number: D2-3356-6
- Dimensions: 146mm by 304.8mm by 121.9mm
- Weight: 2.7kg/6lbs
-
Does the 1SU21005 support an optional snubber resistor braking kit?
- Yes, this is a supported feature on this model.
-
How long can the motor leads be on the 1SU21005?
- These leads can be up to 76 meters total.
-
What type of control method does the 1SU21005 use?
- This drive is pulse-width-modulated.
⭐⭐⭐⭐⭐ 5.0
The 1SU21005 is offers mid-range horsepower in a smaller enclosure profile. This model provides a great trade-off in power and cost-efficiency, making it a popular choice for many operators. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
1SU21005 SP500 |
Description |
1SU21005 By Reliance Electric 200-230VAC 3 Phase Input AC Drive |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model ID | 1SU21005 |
| Manufacturer | Reliance Electric |
| Product Line | SP500 |
| Functional Description | AC Drive |
| Enclosure Rating | NEMA 1 |
| Input Voltage | 230VAC |
| Power Rating | 5HP |
| Operating Temperature | 0° to 40°C |
| Storage Temperature | -40° to 65°C |
| Manual Number | D2-3356-6 |
| Dimensions | 146mm by 304.8mm by 121.9mm |
| Weight | 2.7kg/6lbs |
Frequently Asked Questions | |
| Does the 1SU21005 support an optional snubber resistor braking kit? Yes, this is a supported feature on this model. | |
| How long can the motor leads be on the 1SU21005? These leads can be up to 76 meters total. | |
| What type of control method does the 1SU21005 use? This drive is pulse-width-modulated. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 1SU21005 is offers mid-range horsepower in a smaller enclosure profile. This model provides a great trade-off in power and cost-efficiency, making it a popular choice for many operators. -Automation Industrial Quality Assurance Manager |
|
