- Product Number: 469-P1-HI-A20-T
- Made By: GE Multilin
- Series: 469
- Role: Motor Management Relay
- Phase CT Secondaries: 1A
- DC Power Supply: 90-300VDC
- AC Power Supply: 70-265VAC
- AC Frequency Range: 48-62Hz
- Analog Output Type: 4-20mA
- Digital Inputs: 9
- Serial Ports: 3
- Manual P/N: GEK-106289A
-
What serial standards are supported on the 469-P1-HI-A20-T?
- The 469-P1-HI-A20-T uses 1 RS-232 port and 2 RS-485 ports.
-
Are the digital inputs on the 469-P1-HI-A20-T isolated?
- Yes, these inputs are all opto-isolated.
-
Does the 469-P1-HI-A20-T use the draw-out style case?
- Yes, the 469-P1-HI-A20-T features the unique draw-out construction.
⭐⭐⭐⭐⭐ 5.0
The 469-P1-HI-A20-T has one of the best display types available among the 469 relays. Not only is this display generally easier to read than the base version, but this model also comes with 10Base-T Ethernet support. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
469-P1-HI-A20-T 469 Motor Management Relay |
Description |
469-P1-HI-A20-T By GE Multilin 469 Motor Management Relay |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Product Number | 469-P1-HI-A20-T |
| Made By | GE Multilin |
| Series | 469 |
| Role | Motor Management Relay |
| Phase CT Secondaries | 1A |
| DC Power Supply | 90-300VDC |
| AC Power Supply | 70-265VAC |
| AC Frequency Range | 48-62Hz |
| Analog Output Type | 4-20mA |
| Digital Inputs | 9 |
| Serial Ports | 3 |
| Manual P/N | GEK-106289A |
Frequently Asked Questions | |
| What serial standards are supported on the 469-P1-HI-A20-T? The 469-P1-HI-A20-T uses 1 RS-232 port and 2 RS-485 ports. | |
| Are the digital inputs on the 469-P1-HI-A20-T isolated? Yes, these inputs are all opto-isolated. | |
| Does the 469-P1-HI-A20-T use the draw-out style case? Yes, the 469-P1-HI-A20-T features the unique draw-out construction. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 469-P1-HI-A20-T has one of the best display types available among the 469 relays. Not only is this display generally easier to read than the base version, but this model also comes with 10Base-T Ethernet support. -Automation Industrial Quality Assurance Manager |
|
