- Product Code: 489-P5-LO-A20-E
- Brand Name: GE Multilin
- Unit Family: 489 Generator Management
- Part Type: Relay
- Phase CT Secondaries: 5A
- Power Rating: 20-60VDC, 20-48VAC
- Analog Inputs: 0-1mA, 0-20mA, 4-20mA
- Analog Output: 4-20mA
- Display Type: Enhanced
- Digital Inputs: 9
- CT Primary: 10-10000A
- Manual Name: GEK-106494L
-
What is enhanced about the display on the 489-P5-LO-A20-E compared to a standard model?
- The display on the 489-P5-LO-A20-E is slightly larger and easier to read.
-
Are the digital inputs on the 489-P5-LO-A20-E isolated?
- Yes, each of these inputs is opto-isolated.
-
What kind of communications ports does the 489-P5-LO-A20-E have?
- The 489-P5-LO-A20-E has an RS-232 port on the front, a computer RS-485 port, and an auxiliary RS-485 port.
⭐⭐⭐⭐⭐ 5.0
The 489-P5-LO-A20-E uses the more common CT secondary and analog output options in addition to having one of the improved displays. As such, we highly recommend this model for most low-voltage applications. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
489-P5-LO-A20-E 489 Generator Management Relay |
Description |
489-P5-LO-A20-E By GE Multilin Generator Management Relay NSNB |
Condition |
New Surplus Open Box With 1 Year Warranty. |
Technical Specifications | |
| Product Code | 489-P5-LO-A20-E |
| Brand Name | GE Multilin |
| Unit Family | 489 Generator Management |
| Part Type | Relay |
| Phase CT Secondaries | 5A |
| Power Rating | 20-60VDC, 20-48VAC |
| Analog Inputs | 0-1mA, 0-20mA, 4-20mA |
| Analog Output | 4-20mA |
| Display Type | Enhanced |
| Digital Inputs | 9 |
| CT Primary | 10-10000A |
| Manual Name | GEK-106494L |
Frequently Asked Questions | |
| What is enhanced about the display on the 489-P5-LO-A20-E compared to a standard model? The display on the 489-P5-LO-A20-E is slightly larger and easier to read. | |
| Are the digital inputs on the 489-P5-LO-A20-E isolated? Yes, each of these inputs is opto-isolated. | |
| What kind of communications ports does the 489-P5-LO-A20-E have? The 489-P5-LO-A20-E has an RS-232 port on the front, a computer RS-485 port, and an auxiliary RS-485 port. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 489-P5-LO-A20-E uses the more common CT secondary and analog output options in addition to having one of the improved displays. As such, we highly recommend this model for most low-voltage applications. -Automation Industrial Quality Assurance Manager |
|
