- Unit ID: 57C430A
- Original Manufacturer: Reliance Electric
- Series Name: AutoMax
- Part Type: Processor Module
- Designation: 6010
- CPU: Motorola 68010 (16-Bit)
- Processor Speed: 8MHz
- Memory Package: 256K Parity RAM
- Max CPUs Per Rack: 4
- Average Power Dissipation: 15W
- Dimensions: 11.75" x 1.25" x 7.37"
- User Manual: J-3650-6
-
What programming languages are supported on the 57C430A?
- The 57C430A is programmed via BASIC, Ladder Logic, and Control Block.
-
Is the 57C430A battery-backed?
- Yes, the 57C430A has both a lithium battery and supercapacitor to help prevent data loss during a power loss event.
-
What type of serial port does the 57C430A have?
- The 57C430A has two RS-232C ports for communications.
⭐⭐⭐⭐ 4.0
The 57C430A is the lowest-rated AutoMax processor module in both speed and memory size. This model is still great in less-demanding applications, but it may struggle to keep up the more complex things get unless you are using multiple simultaneously. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
57C430A AutoMax PLC |
Description |
57C430A By Reliance Electric 6010 Processor Module |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Unit ID | 57C430A |
| Original Manufacturer | Reliance Electric |
| Series Name | AutoMax |
| Part Type | Processor Module |
| Designation | 6010 |
| CPU | Motorola 68010 (16-Bit) |
| Processor Speed | 8MHz |
| Memory Package | 256K Parity RAM |
| Max CPUs Per Rack | 4 |
| Average Power Dissipation | 15W |
| Dimensions | 11.75" x 1.25" x 7.37" |
| User Manual | J-3650-6 |
Frequently Asked Questions | |
| What programming languages are supported on the 57C430A? The 57C430A is programmed via BASIC, Ladder Logic, and Control Block. | |
| Is the 57C430A battery-backed? Yes, the 57C430A has both a lithium battery and supercapacitor to help prevent data loss during a power loss event. | |
| What type of serial port does the 57C430A have? The 57C430A has two RS-232C ports for communications. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The 57C430A is the lowest-rated AutoMax processor module in both speed and memory size. This model is still great in less-demanding applications, but it may struggle to keep up the more complex things get unless you are using multiple simultaneously. -Automation Industrial Quality Assurance Manager |
|
