- Product ID: 8516-039
- Unit Manufacturer: Woodward
- Family: TG-13
- Part Type: Governor
- Work Output: 12ft-lbs
- Rotation Direction: CCW
- Speed Rating: 4000rpm
- High Speed (2°): 4500rpm
- Rated Speed (38°): 3600rpm
- Rated Speed (2°): 4035rpm
- Low Speed (2°): 2400rpm
- OTD Speed: 4400rpm
-
How do you set the speed on the 8516-039?
- The 8516-039 uses screw-based speed setting.
-
Where can I find more information about the 8516-039?
- The TG-13 series is further detailed in the 54103 manual from Woodward.
-
What newer model is the 8516-039 equivalent to?
- The 8516-039 is equivalent to the 8516-179.
⭐⭐⭐⭐⭐ 5.0
The 8516-039 is one of the more popular counterclockwise options of TG-13 governor largely due to its mid-range speed rating. It is always recommended to get a new-condition replacement for governors like this one whenever possible due to the loads they are regularly exposed to. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
8516-039 Turbine Governor |
Description |
8516-039 By Woodward Hydraulic Steam Turbine Speed Governor NSNB |
Condition |
New Surplus Open Box With 1 Year Warranty. |
Technical Specifications | |
| Product ID | 8516-039 |
| Unit Manufacturer | Woodward |
| Family | TG-13 |
| Part Type | Governor |
| Work Output | 12ft-lbs |
| Rotation Direction | CCW |
| Speed Rating | 4000rpm |
| High Speed (2°) | 4500rpm |
| Rated Speed (38°) | 3600rpm |
| Rated Speed (2°) | 4035rpm |
| Low Speed (2°) | 2400rpm |
| OTD Speed | 4400rpm |
Frequently Asked Questions | |
| How do you set the speed on the 8516-039? The 8516-039 uses screw-based speed setting. | |
| Where can I find more information about the 8516-039? The TG-13 series is further detailed in the 54103 manual from Woodward. | |
| What newer model is the 8516-039 equivalent to? The 8516-039 is equivalent to the 8516-179. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The 8516-039 is one of the more popular counterclockwise options of TG-13 governor largely due to its mid-range speed rating. It is always recommended to get a new-condition replacement for governors like this one whenever possible due to the loads they are regularly exposed to. -Automation Industrial Quality Assurance Manager |
|
