- Unit ID: AH385128U004
- Part Manufacturer: Eurotherm
- Product Line: 590 Link
- Model Description: Power Supply
- Version: Three-Board
- Input Phases: 3
- Input Voltage: 208/230/380/415VAC
- Input Frequency: 50/60Hz
- Control Supply: 110/240VAC
- Field Supply: 10A, 500V
- Isolating Contactor: 10A, 250V
- Manual: HA352494
-
Is the AH385128U004 the same thing as an AH385128U104?
- These boards are extremely similar in function but not identical in field supply.
-
Is the control supply on the AH385128U004 fuse-protected?
- Yes, this supply is protected by a 400mA, 250V fuse.
-
Is the AH385128U004 sensitive to phase rotation?
- No, the AH385128U004 is not sensitive to phase rotation.
⭐⭐⭐⭐⭐ 5.0
The AH385128U004 is a key part of the common three-board type power supply setup for certain 590 drives. These supply types are super popular among operators thanks to their excellent protection features, wide range of accepted voltages, and adjustment-free design when it comes to things like input frequency. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
AH385128U004 |
Description |
AH385128U004 By Eurotherm Power Board NSNB |
Condition |
New Surplus Open Box With 1 Year Warranty |
Technical Specifications | |
| Unit ID | AH385128U004 |
| Part Manufacturer | Eurotherm |
| Product Line | 590 Link |
| Model Description | Power Supply |
| Version | Three-Board |
| Input Phases | 3 |
| Input Voltage | 208/230/380/415VAC |
| Input Frequency | 50/60Hz |
| Control Supply | 110/240VAC |
| Field Supply | 10A, 500V |
| Isolating Contactor | 10A, 250V |
| Manual | HA352494 |
Frequently Asked Questions | |
| Is the AH385128U004 the same thing as an AH385128U104? These boards are extremely similar in function but not identical in field supply. | |
| Is the control supply on the AH385128U004 fuse-protected? Yes, this supply is protected by a 400mA, 250V fuse. | |
| Is the AH385128U004 sensitive to phase rotation? No, the AH385128U004 is not sensitive to phase rotation. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The AH385128U004 is a key part of the common three-board type power supply setup for certain 590 drives. These supply types are super popular among operators thanks to their excellent protection features, wide range of accepted voltages, and adjustment-free design when it comes to things like input frequency. -Automation Industrial Quality Assurance Manager |
|
