- Product No: B-LINK-AC-OP
- Manufacturer Name: Schneider Electric
- Unit Series: bLink Repeaters
- Functionality: Electronic Repeater
- Voltage Type: AC
- Power Rating: 115/230VAC
- Switch-Selectable: Yes
- Comm Speed: 9600-76.8Kbps
- Open Class: Yes
- Fuse Type: 2A
- Dimensions: 6.92˝ x 6.10˝ x 1.960˝
- Weight: 2.74lb
-
How much propagation delay is there with the B-LINK-AC-OP?
- The B-LINK-AC-OP has a maximum delay of 0.5µs.
-
What type of power connector does the B-LINK-AC-OP use?
- The B-LINK-AC-OP uses a 3-position barrier strip type connector for power input.
-
What kind of overload protections are there on the B-LINK-AC-OP?
- The B-LINK-AC-OP has both fuse and MOV protections.
⭐⭐⭐⭐ 4.0
The B-LINK-AC-OP can support incredibly long field bus communications, making it a great repeater for applications that need more than the standard 4,000 foot limit. It is important to note that this is one of the non-enclosed models of this repeater, so it is not able to be mounted in the same conditions as a standard version. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
B-LINK-AC-OP Andover Continuum |
Description |
B-LINK-AC-OP By Schneider Electric 05-1001-110 Electronic Repeater NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Product No | B-LINK-AC-OP |
| Manufacturer Name | Schneider Electric |
| Unit Series | bLink Repeaters |
| Functionality | Electronic Repeater |
| Voltage Type | AC |
| Power Rating | 115/230VAC |
| Switch-Selectable | Yes |
| Comm Speed | 9600-76.8Kbps |
| Open Class | Yes |
| Fuse Type | 2A |
| Dimensions | 6.92˝ x 6.10˝ x 1.960˝ |
| Weight | 2.74lb |
Frequently Asked Questions | |
| How much propagation delay is there with the B-LINK-AC-OP? The B-LINK-AC-OP has a maximum delay of 0.5µs. | |
| What type of power connector does the B-LINK-AC-OP use? The B-LINK-AC-OP uses a 3-position barrier strip type connector for power input. | |
| What kind of overload protections are there on the B-LINK-AC-OP? The B-LINK-AC-OP has both fuse and MOV protections. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The B-LINK-AC-OP can support incredibly long field bus communications, making it a great repeater for applications that need more than the standard 4,000 foot limit. It is important to note that this is one of the non-enclosed models of this repeater, so it is not able to be mounted in the same conditions as a standard version. -Automation Industrial Quality Assurance Manager |
|
