- Model Number: CRM-510
- Manufactured By: Square D
- Original Series: SY/MAX
- Subseries: SY/NET
- Part Type: Interface Module
- Interface Type: LAN
- COM Ports: 2
- Standard: RS-422
- Baud Rate: ≤9600
- SY/NET Connectors: 1
- Supported Cable Length: 2/10/30ft
- Bulletin No: 30598-257-02
-
Can the CRM-510 support current loop devices?
- Yes, but a special cable is required for this connection.
-
Are the two channels on the CRM-510 independent from each other?
- Yes, each channel is independent.
-
How do you select the address on the CRM-510?
- This is done via thumbwheel switches.
⭐⭐⭐⭐⭐ 5.0
If you have any local RS-422 type devices you would like to link to your SY/MAX system, the CRM-510 is an excellent tool for the job. The dual-channel design of the CRM-510 allows it to handle two different devices simultaneously, reducing the number of slots required in larger systems. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
8030-CRM-510 Symax Class 8030 |
Description |
CRM-510 By Square D Sy/Max Class 8030 Local Area Network Interface Module |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model Number | CRM-510 |
| Manufactured By | Square D |
| Original Series | SY/MAX |
| Subseries | SY/NET |
| Part Type | Interface Module |
| Interface Type | LAN |
| COM Ports | 2 |
| Standard | RS-422 |
| Baud Rate | ≤9600 |
| SY/NET Connectors | 1 |
| Supported Cable Length | 2/10/30ft |
| Bulletin No | 30598-257-02 |
Frequently Asked Questions | |
| Can the CRM-510 support current loop devices? Yes, but a special cable is required for this connection. | |
| Are the two channels on the CRM-510 independent from each other? Yes, each channel is independent. | |
| How do you select the address on the CRM-510? This is done via thumbwheel switches. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
If you have any local RS-422 type devices you would like to link to your SY/MAX system, the CRM-510 is an excellent tool for the job. The dual-channel design of the CRM-510 allows it to handle two different devices simultaneously, reducing the number of slots required in larger systems. -Automation Industrial Quality Assurance Manager |
|
