- Model Code: D0-06DA
- Producer: Automation Direct
- Part Family: DL06
- Unit Description: Micro PLC
- Supply Power: 100-240VAC, 40VA
- Inputs: 20
- Input Range: 10.8-26.4VDC
- Input Commons: 5
- Outputs: 16
- Output Range: 17-240VAC
- Frequency: 47-63Hz
- Output Commons: 4
-
Does the D0-06DA have any internal fuses?
- No, the D0-06DA does not have any built-in fuses.
-
Can external fuses be used with the D0-06DA?
- Yes, this is recommended for the AC outputs.
-
Does the D0-06DA support expansion?
- Yes, the D0-06DA can be used with expansion modules.
⭐⭐⭐⭐⭐ 5.0
The D0-06DA manages to fit all the necessary PLC features such as the input/outputs, processor, and power supply all in one compact device. This DL06 model is a significant upgrade over the DL05 versions when it comes to areas such as processing and memory storage. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
D0-06DA DirectLogic 06 |
Description |
D0-06DA By Automation Direct 120-240 VAC Discrete Input and Output Module NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Model Code | D0-06DA |
| Producer | Automation Direct |
| Part Family | DL06 |
| Unit Description | Micro PLC |
| Supply Power | 100-240VAC, 40VA |
| Inputs | 20 |
| Input Range | 10.8-26.4VDC |
| Input Commons | 5 |
| Outputs | 16 |
| Output Range | 17-240VAC |
| Frequency | 47-63Hz |
| Output Commons | 4 |
Frequently Asked Questions | |
| Does the D0-06DA have any internal fuses? No, the D0-06DA does not have any built-in fuses. | |
| Can external fuses be used with the D0-06DA? Yes, this is recommended for the AC outputs. | |
| Does the D0-06DA support expansion? Yes, the D0-06DA can be used with expansion modules. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The D0-06DA manages to fit all the necessary PLC features such as the input/outputs, processor, and power supply all in one compact device. This DL06 model is a significant upgrade over the DL05 versions when it comes to areas such as processing and memory storage. -Automation Industrial Quality Assurance Manager |
|
