- Model ID: D2-08TA
- Made By: Automation Direct
- Series: DL205
- Part Designation: Discrete Output Module
- Total Outputs: 8
- Output Type: Triac SSR
- Operating Voltage Range: 15-264VAC
- Frequency Range: 47-63Hz
- Minimum Load Current: 10mA
- Max Load Current (Point): 0.5A
- Max Load Current (Common): 4A
- Weight: 2.8oz
-
How many commons are there on the D2-08TA?
- The D2-08TA only has 1 common, though it takes up 2 terminal points.
-
Is the D2-08TA fuse-protected?
- Yes, the D2-08TA has one slow blow, 6.3A fuse.
-
Can you replace the fuse on the D2-08TA?
- No, this fuse is non-replaceable.
⭐⭐⭐⭐⭐ 5.0
The D2-08TA can output across a much wider voltage range than its F2 counterpart. Additionally, because these two modules share the same removable terminal block, this portion of the module can be very easy to replace. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
D2-08TA DirectLogic 205 |
Description |
D2-08TA By Automation Direct 8-Point Discrete Output Module |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model ID | D2-08TA |
| Made By | Automation Direct |
| Series | DL205 |
| Part Designation | Discrete Output Module |
| Total Outputs | 8 |
| Output Type | Triac SSR |
| Operating Voltage Range | 15-264VAC |
| Frequency Range | 47-63Hz |
| Minimum Load Current | 10mA |
| Max Load Current (Point) | 0.5A |
| Max Load Current (Common) | 4A |
| Weight | 2.8oz |
Frequently Asked Questions | |
| How many commons are there on the D2-08TA? The D2-08TA only has 1 common, though it takes up 2 terminal points. | |
| Is the D2-08TA fuse-protected? Yes, the D2-08TA has one slow blow, 6.3A fuse. | |
| Can you replace the fuse on the D2-08TA? No, this fuse is non-replaceable. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The D2-08TA can output across a much wider voltage range than its F2 counterpart. Additionally, because these two modules share the same removable terminal block, this portion of the module can be very easy to replace. -Automation Industrial Quality Assurance Manager |
|
