- Model Name: D3-08TD2
- Made By: Automation Direct
- Family ID: DL305
- Product Function: DC Output Module
- Outputs: 8
- Source/Sink: Sourcing
- Commons: 2
- Operating Voltage: 5-24VDC
- Peak Voltage: 40VDC
- Minimum Load: 1mA
- Fuses: 2 (3A)
- Fuse Type: Non-Replaceable
-
What type of commons does the D3-08TD2 have?
- The D3-08TD2 has internally connected commons.
-
What type of outputs does the D3-08TD2 have?
- The D3-08TD2 uses NPN transistor, emitter follower type outputs.
-
Does the D3-08TD2 have a removable terminal design?
- No, this module has a non-removable terminal design.
⭐⭐⭐⭐⭐ 5.0
The D3-08TD2 offers a respectable amount of current sourcing outputs to a DC type DL305 setup. This model is generally compatible with low-voltage systems without an issue. Overall, this is a straightforward, high-quality product. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
D3-08TD2 DirectLogic 305 |
Description |
D3-08TD2 by Automation Direct 24VDC Discrete Output Module DL305 DirectLOGIC 305 |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty |
Technical Specifications | |
| Model Name | D3-08TD2 |
| Made By | Automation Direct |
| Family ID | DL305 |
| Product Function | DC Output Module |
| Outputs | 8 |
| Source/Sink | Sourcing |
| Commons | 2 |
| Operating Voltage | 5-24VDC |
| Peak Voltage | 40VDC |
| Minimum Load | 1mA |
| Fuses | 2 (3A) |
| Fuse Type | Non-Replaceable |
Frequently Asked Questions | |
| What type of commons does the D3-08TD2 have? The D3-08TD2 has internally connected commons. | |
| What type of outputs does the D3-08TD2 have? The D3-08TD2 uses NPN transistor, emitter follower type outputs. | |
| Does the D3-08TD2 have a removable terminal design? No, this module has a non-removable terminal design. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The D3-08TD2 offers a respectable amount of current sourcing outputs to a DC type DL305 setup. This model is generally compatible with low-voltage systems without an issue. Overall, this is a straightforward, high-quality product. -Automation Industrial Quality Assurance Manager |
|
