- Product ID: D3-10B-1
- Made By: Automation Direct
- Family: DirectLogic 305
- Functional Description: Base Unit
- AC/DC Powered: AC
- Input Voltage: 85-264VAC
- Frequency: 47-63Hz
- Max Inrush Current: 30A (1ms)
- Dielectric Strength: 2000VAC (1min)
- Auxiliary 24VDC Output: Yes, 100mA Max
- Fuse Rating: 2A (250V)
- Replaceable Fuses: No
-
Does the D3-10B-1 have a local CPU base?
- Yes, this is included on the D3-10B-1.
-
How much power does the D3-10B-1 consume?
- The D3-10B-1 consumes up to a maximum of 85VA during operation.
-
What kind of expansion bases are supported on the D3-10B-1?
- The D3-10B-1 can support either a 10-slot or a 5-slot expansion base
⭐⭐⭐⭐⭐ 5.0
The D3-10B-1 is one of the largest DirectLogic 305 bases in terms of slot capacity. This base unit also supports an expansion base to further increase this capacity. If you are operating a larger, AC-powered application and the size difference is not a factor, this will likely be the most effective choice of base unit available to you. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
D3-10B-1 DirectLogic 305 |
Description |
D3-10B-1 By Direct Logic 10-Slot Panel Mount I/O 305 Series NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Product ID | D3-10B-1 |
| Made By | Automation Direct |
| Family | DirectLogic 305 |
| Functional Description | Base Unit |
| AC/DC Powered | AC |
| Input Voltage | 85-264VAC |
| Frequency | 47-63Hz |
| Max Inrush Current | 30A (1ms) |
| Dielectric Strength | 2000VAC (1min) |
| Auxiliary 24VDC Output | Yes, 100mA Max |
| Fuse Rating | 2A (250V) |
| Replaceable Fuses | No |
Frequently Asked Questions | |
| Does the D3-10B-1 have a local CPU base? Yes, this is included on the D3-10B-1. | |
| How much power does the D3-10B-1 consume? The D3-10B-1 consumes up to a maximum of 85VA during operation. | |
| What kind of expansion bases are supported on the D3-10B-1? The D3-10B-1 can support either a 10-slot or a 5-slot expansion base | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The D3-10B-1 is one of the largest DirectLogic 305 bases in terms of slot capacity. This base unit also supports an expansion base to further increase this capacity. If you are operating a larger, AC-powered application and the size difference is not a factor, this will likely be the most effective choice of base unit available to you. -Automation Industrial Quality Assurance Manager |
|
