- Unit ID: DC2-70G
- Made By: Reliance Electric
- Series: DC2
- Designation: Drive
- Control Type: Speed Control
- Basic/Plus: Basic
- Optional Features: None
- Enclosed: Yes
- Enclosure Type: NEMA 12
- Operating Temperature: 0° to 40°C
- Storage Temperature: -30° to 65°C
- Manual Number: D2-3231
-
What type of voltage rectifier is used in the DC2-70G?
- The DC2-70G uses the standard half-controlled, full-wave armature voltage rectifier found in all DC2 controllers.
-
How is speed adjusted with the DC2-70G?
- The DC2-70G uses a potentiometer for speed control adjustment.
-
Can you repair my DC2-70G?
- Yes, we offer this service here at Automation Industrial.
⭐⭐⭐⭐⭐ 5.0
The DC2-70G is one of the basic models of speed control within the DC2 series. Though this version does not come with any advanced optional features, it still has the base protections found in all DC2 drives such as overload, short circuit, and line transient. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DC2-70G DC2 |
Description |
DC2-70G By Reliance Electric 2HP 115/230VACDC Motor Controller |
Condition |
Pre-Owned Clean and Tested With 1 Year Warranty. |
Technical Specifications | |
| Unit ID | DC2-70G |
| Made By | Reliance Electric |
| Series | DC2 |
| Designation | Drive |
| Control Type | Speed Control |
| Basic/Plus | Basic |
| Optional Features | None |
| Enclosed | Yes |
| Enclosure Type | NEMA 12 |
| Operating Temperature | 0° to 40°C |
| Storage Temperature | -30° to 65°C |
| Manual Number | D2-3231 |
Frequently Asked Questions | |
| What type of voltage rectifier is used in the DC2-70G? The DC2-70G uses the standard half-controlled, full-wave armature voltage rectifier found in all DC2 controllers. | |
| How is speed adjusted with the DC2-70G? The DC2-70G uses a potentiometer for speed control adjustment. | |
| Can you repair my DC2-70G? Yes, we offer this service here at Automation Industrial. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The DC2-70G is one of the basic models of speed control within the DC2 series. Though this version does not come with any advanced optional features, it still has the base protections found in all DC2 drives such as overload, short circuit, and line transient. -Automation Industrial Quality Assurance Manager |
|
