- Product ID: DC3N-12D-4X-010-AI
- OEM: Reliance Electric
- Model Line: DC3 Drives
- Description: Non-Regenerative DC Drive
- Enclosure Type: NEMA 12/4/4X
- Voltage Rating: 115/230VAC
- HP Rating (115VAC): 0.125-1
- HP Rating (230VAC): 0.25-2
- Max Armature Current: 10A (DC)
- Ambient Temperature Range: 10° to 40°C
- Certifications: CE, cUL, UL
- Manual Number: D2-3451
-
What condition is this DC3N-12D-4X-010-AI in?
- This DC3N-12D-4X-010-AI is still in factory-packaged, new condition.
-
What is the maximum elevation the DC3N-12D-4X-010-AI is rated for?
- The DC3N-12D-4X-010-AI can operate at heights up to 3300 feet before derating becomes necessary.
-
What altitudes can the DC3N-12D-4X-010-AI operate at with maximum derating?
- The absolute maximum altitude the DC3N-12D-4X-010-AI can operate in is 10,000 feet with maximum derating.
⭐⭐⭐⭐⭐ 5.0
This DC3N-12D-4X-010-AI is in excellent condition and in one of the highest-rated enclosures available. These factors combine to make this one of the single best long-term DC3 drive options on the market today. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DC3N-12D-4X-010-AI DC3 |
Description |
DC3N-12D-4X-010-AI By Reliance Electric Single Phase DC Drive NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Product ID | DC3N-12D-4X-010-AI |
| OEM | Reliance Electric |
| Model Line | DC3 Drives |
| Description | Non-Regenerative DC Drive |
| Enclosure Type | NEMA 12/4/4X |
| Voltage Rating | 115/230VAC |
| HP Rating (115VAC) | 0.125-1 |
| HP Rating (230VAC) | 0.25-2 |
| Max Armature Current | 10A (DC) |
| Ambient Temperature Range | 10° to 40°C |
| Certifications | CE, cUL, UL |
| Manual Number | D2-3451 |
Frequently Asked Questions | |
| What condition is this DC3N-12D-4X-010-AI in? This DC3N-12D-4X-010-AI is still in factory-packaged, new condition. | |
| What is the maximum elevation the DC3N-12D-4X-010-AI is rated for? The DC3N-12D-4X-010-AI can operate at heights up to 3300 feet before derating becomes necessary. | |
| What altitudes can the DC3N-12D-4X-010-AI operate at with maximum derating? The absolute maximum altitude the DC3N-12D-4X-010-AI can operate in is 10,000 feet with maximum derating. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
This DC3N-12D-4X-010-AI is in excellent condition and in one of the highest-rated enclosures available. These factors combine to make this one of the single best long-term DC3 drive options on the market today. -Automation Industrial Quality Assurance Manager |
|
