- Unit Code: DO-4-R-O
- Equipment Manufacturer: Schneider Electric
- Family Name: Andover Continuum
- Functional Description: Relay Output Module
- Overrides: Yes
- Relay Outputs: 4
- Output Type: Form C
- Current Rating: 5A
- Voltage Rating: 240VAC
- Isolation: 5000V
- MOVs: Yes
- Output Resolution: 0.1sec
-
What control modes are supported on the DO-4-R-O?
- The DO-4-R-O supports both on/off as well as PWM control methods.
-
Can you make a tri-state output with the DO-4-R-O?
- Yes, the DO-4-R-O supports combining adjacent outputs into a tri-state output.
-
What does the "-O" indicate in the DO-4-R-O part number?
- This indicates that this is an override-equipped model.
⭐⭐⭐⭐⭐ 5.0
The relay outputs on the DO-4-R-O are all well-labeled and come with their own override switches in addition to all the base features of this module type. These override switches can even be automatically controlled to make the process even easier. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DO-4-R-O Andover Continuum |
Description |
DO-4-R-O By Schneider Electric DO-4 4-Digital Relay Output Module w/ Overrides |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Unit Code | DO-4-R-O |
| Equipment Manufacturer | Schneider Electric |
| Family Name | Andover Continuum |
| Functional Description | Relay Output Module |
| Overrides | Yes |
| Relay Outputs | 4 |
| Output Type | Form C |
| Current Rating | 5A |
| Voltage Rating | 240VAC |
| Isolation | 5000V |
| MOVs | Yes |
| Output Resolution | 0.1sec |
Frequently Asked Questions | |
| What control modes are supported on the DO-4-R-O? The DO-4-R-O supports both on/off as well as PWM control methods. | |
| Can you make a tri-state output with the DO-4-R-O? Yes, the DO-4-R-O supports combining adjacent outputs into a tri-state output. | |
| What does the "-O" indicate in the DO-4-R-O part number? This indicates that this is an override-equipped model. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The relay outputs on the DO-4-R-O are all well-labeled and come with their own override switches in addition to all the base features of this module type. These override switches can even be automatically controlled to make the process even easier. -Automation Industrial Quality Assurance Manager |
|
