- Model Number: DPG-2223-002
- OEM: Woodward
- Series: DPG-2223-00X
- Product Type: Digital Controller
- Droop Adjustment Range: 0-10% Set Speed
- Governing Speed Range: 500 MPU Hz to 11,000 MPU Hz
- Engine Speed Measurement Range: 10 MPU Hz to 14,000 MPU Hz
- Operating Voltage: 9-30VDC
- Output Current: 7A Max
- Terminal Type: Euro
- Weight: 12oz
- Manual Name: 36522G
-
Can the DPG-2223-002 be calibrated via a Universal PST?
- Yes, this is supported on the DPG-2223-002.
-
What ambient operating temperature range is acceptable for the DPG-2223-002?
- The DPG-2223-002 can handle conditions from -40° to 85°C.
-
How protective is the enclosure of the DPG-2223-002?
- This die-cast enclosure is conformal coated to allow for water, dust, and oil resistance.
⭐⭐⭐⭐⭐ 5.0
The DPG-2223-002 is incredibly compact and durable for a controller of this type. This model has mostly identical features to the "001" variant, but with Hz/RPM overspeed parameter setting rather than percentage. Additionally, this model is easier to configure for droop applications than its counterpart. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DPG-2223-002 |
Description |
DPG-2223-002 By Woodward 9-30VDC 2-Digit LED Display Isochronous Speed Control |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model Number | DPG-2223-002 |
| OEM | Woodward |
| Series | DPG-2223-00X |
| Product Type | Digital Controller |
| Droop Adjustment Range | 0-10% Set Speed |
| Governing Speed Range | 500 MPU Hz to 11,000 MPU Hz |
| Engine Speed Measurement Range | 10 MPU Hz to 14,000 MPU Hz |
| Operating Voltage | 9-30VDC |
| Output Current | 7A Max |
| Terminal Type | Euro |
| Weight | 12oz |
| Manual Name | 36522G |
Frequently Asked Questions | |
| Can the DPG-2223-002 be calibrated via a Universal PST? Yes, this is supported on the DPG-2223-002. | |
| What ambient operating temperature range is acceptable for the DPG-2223-002? The DPG-2223-002 can handle conditions from -40° to 85°C. | |
| How protective is the enclosure of the DPG-2223-002? This die-cast enclosure is conformal coated to allow for water, dust, and oil resistance. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The DPG-2223-002 is incredibly compact and durable for a controller of this type. This model has mostly identical features to the "001" variant, but with Hz/RPM overspeed parameter setting rather than percentage. Additionally, this model is easier to configure for droop applications than its counterpart. -Automation Industrial Quality Assurance Manager |
|
