- Part ID: F4-04DAS-1
- OEM: Facts Engineering
- Model Series: DirectLogic 405
- Unit Type: Isolated Current Output Module
- Current Range: 4-20mA
- Resolution: 16-bit
- Channels: 4
- Sourcing/Sinking: Sourcing
- Isolation: ±750V Continuous
- Load Impedance: 0-525Ω
- Loop Supply Range: 18-32VDC
- Relative Humidity (Noncondensing): 5% to 95%
-
Can the F4-04DAS-1 be configured for 0-20mA output?
- No, the F4-04DAS-1 is 4-20mA only.
-
How much power does the F4-04DAS-1 use?
- The F4-04DAS-1 takes 100mA from the base and 50mA from the external supply per channel.
-
Can you use the F4-04DAS-1 with an H4-EBC?
- Yes, so long as the H4-EBC is at least version 2.1.46.
⭐⭐⭐⭐ 4.0
The F4-04DAS-1 is one of the few isolated DL405 analog output modules available. This model is somewhat more limited in its use cases than other versions however, as it is only suitable for 4-20mA, current sourcing output signals. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
F4-04DAS-1 DirectLogic 405 |
Description |
F4-04DAS-1 by Facts Engineering Analog Input Module DL405 DirectLOGIC 405 |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Part ID | F4-04DAS-1 |
| OEM | Facts Engineering |
| Model Series | DirectLogic 405 |
| Unit Type | Isolated Current Output Module |
| Current Range | 4-20mA |
| Resolution | 16-bit |
| Channels | 4 |
| Sourcing/Sinking | Sourcing |
| Isolation | ±750V Continuous |
| Load Impedance | 0-525Ω |
| Loop Supply Range | 18-32VDC |
| Relative Humidity (Noncondensing) | 5% to 95% |
Frequently Asked Questions | |
| Can the F4-04DAS-1 be configured for 0-20mA output? No, the F4-04DAS-1 is 4-20mA only. | |
| How much power does the F4-04DAS-1 use? The F4-04DAS-1 takes 100mA from the base and 50mA from the external supply per channel. | |
| Can you use the F4-04DAS-1 with an H4-EBC? Yes, so long as the H4-EBC is at least version 2.1.46. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The F4-04DAS-1 is one of the few isolated DL405 analog output modules available. This model is somewhat more limited in its use cases than other versions however, as it is only suitable for 4-20mA, current sourcing output signals. -Automation Industrial Quality Assurance Manager |
|
