- Part Name: FN-DA02AH41
- OEM: Pro-face
- Family: Flex Network
- Description: Digital-to-Analog Conversion Module
- Channels: 2
- Voltage Output: 0-10V
- Current Output: 0-20mA, 4-20mA
- Switchover Method: Terminals
- Input Voltage Range: 20.4-28.8VDC
- Power Consumption: 2.4W Max
- Ingress Protection: IP30
- Pollution Degree: 2
-
How long does conversion take on the FN-DA02AH41?
- The FN-DA02AH41 has a maximum conversion time of 2 milliseconds.
-
What resolution are the outputs on the FN-DA02AH41?
- The FN-DA02AH41 has 12-bit outputs.
-
Does the FN-DA02AH41 have any noteworthy agency approvals?
- Yes, the FN-AD04AH11 is both UL/cUL Listed as well as CE Marked.
⭐⭐⭐⭐ 4.0
The only tricky part about setting up the FN-DA02AH41 is properly wiring the terminals for your desired analog output. Other than this, the module is extremely straightforward to operate and easy to mount via either a panel or DIN rail. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
FN-DA02AH41 Flex Network Series |
Description |
FN-DA02AH41 By Proface Xycom 24VDC 2-Channel Analog Output Module |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Part Name | FN-DA02AH41 |
| OEM | Pro-face |
| Family | Flex Network |
| Description | Digital-to-Analog Conversion Module |
| Channels | 2 |
| Voltage Output | 0-10V |
| Current Output | 0-20mA, 4-20mA |
| Switchover Method | Terminals |
| Input Voltage Range | 20.4-28.8VDC |
| Power Consumption | 2.4W Max |
| Ingress Protection | IP30 |
| Pollution Degree | 2 |
Frequently Asked Questions | |
| How long does conversion take on the FN-DA02AH41? The FN-DA02AH41 has a maximum conversion time of 2 milliseconds. | |
| What resolution are the outputs on the FN-DA02AH41? The FN-DA02AH41 has 12-bit outputs. | |
| Does the FN-DA02AH41 have any noteworthy agency approvals? Yes, the FN-AD04AH11 is both UL/cUL Listed as well as CE Marked. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The only tricky part about setting up the FN-DA02AH41 is properly wiring the terminals for your desired analog output. Other than this, the module is extremely straightforward to operate and easy to mount via either a panel or DIN rail. -Automation Industrial Quality Assurance Manager |
|
