- Product No: FRN015F1S-4U
- OEM: Fuji Electric
- Series: FRENIC-Eco
- Part Type: Inverter
- Horsepower Rating: 15
- Voltage: 460V
- Phases: 3
- Terminal Block Type: Euro
- Applications: Indoor Only
- Operating Temperature: -10° to 50°C
- Storage Temperature (Short Term): -25° to 70°C
- Humidity: 5% to 95%
-
What are the dimensions of the FRN015F1S-4U?
- The FRN015F1S-4U measures approximately 8.66 inches wide, 10.2 inches high, and 8.46 inches deep.
-
What size of terminal screw does the FRN015F1S-4U use?
- The FRN015F1S-4U uses M5 terminal screws.
-
What kind of MCCB or GFCIs should be used with the FRN015F1S-4U?
- The FRN015F1S-4U is rated for use with 30A with DCR or 40A without.
⭐⭐⭐⭐⭐ 5.0
The FRN015F1S-4U has low power loss, common horsepower/voltage ratings, and is EU Low Voltage Directive conformant. Overall, this is one of the best FRENIC-Eco inverters in terms of general compatibility. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
FRN015F1S-4U |
Description |
Fuji Electric FRN015F1S-4U Adjustable Frequency Drive NEW |
Condition |
New Surplus Factory Package Original Factory Packaged. With 1 Year Warranty. |
Technical Specifications | |
| Product No | FRN015F1S-4U |
| OEM | Fuji Electric |
| Series | FRENIC-Eco |
| Part Type | Inverter |
| Horsepower Rating | 15 |
| Voltage | 460V |
| Phases | 3 |
| Terminal Block Type | Euro |
| Applications | Indoor Only |
| Operating Temperature | -10° to 50°C |
| Storage Temperature (Short Term) | -25° to 70°C |
| Humidity | 5% to 95% |
Frequently Asked Questions | |
| What are the dimensions of the FRN015F1S-4U? The FRN015F1S-4U measures approximately 8.66 inches wide, 10.2 inches high, and 8.46 inches deep. | |
| What size of terminal screw does the FRN015F1S-4U use? The FRN015F1S-4U uses M5 terminal screws. | |
| What kind of MCCB or GFCIs should be used with the FRN015F1S-4U? The FRN015F1S-4U is rated for use with 30A with DCR or 40A without. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The FRN015F1S-4U has low power loss, common horsepower/voltage ratings, and is EU Low Voltage Directive conformant. Overall, this is one of the best FRENIC-Eco inverters in terms of general compatibility. -Automation Industrial Quality Assurance Manager |
|
