- Product Number: FRN020F1S-2U
- Original Manufacturer: Fuji Electric
- Family: FRENIC-Eco
- Part Type: Inverter
- Horsepower Rating: 20HP
- Output Voltage: 0-240V
- Output Current: 60A
- Voltage Phases: 3
- Overload: 120%, 1 Min
- Inputs: 7 Digital, 3 Analog
- Outputs: 3 Transistor, 2 Gen Purpose, 3 Alarm
- Enclosure Rating: IP20
-
What I/O option cards are compatible with the FRN020F1S-2U?
- The FRN020F1S-2U can be used with the OPC-F1-RY or OPC-115V option cards.
-
What communication options are available for the FRN020F1S-2U?
- The FRN020F1S-2U can be used with optional DeviceNet, Modbus RTU, Profibus, CC-Link, and Ethernet option cards.
-
How much does the FRN020F1S-2U weigh?
- The FRN020F1S-2U weighs approximately 9.7 kilograms, or 21 pounds.
⭐⭐⭐⭐⭐ 5.0
If you are operating a 200V fan and pump system, the FRN020F1S-2U is one of the most efficient inverters available. This model still has a high horsepower rating while maintaining relatively low power loss during operation. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
FRN020F1S-2U |
Description |
Fuji Electric FRN020F1S-2U 20 HP Drive New |
Condition |
New Surplus Factory Package Original Factory Packaged. With 1 Year Warranty. |
Technical Specifications | |
| Product Number | FRN020F1S-2U |
| Original Manufacturer | Fuji Electric |
| Family | FRENIC-Eco |
| Part Type | Inverter |
| Horsepower Rating | 20HP |
| Output Voltage | 0-240V |
| Output Current | 60A |
| Voltage Phases | 3 |
| Overload | 120%, 1 Min |
| Inputs | 7 Digital, 3 Analog |
| Outputs | 3 Transistor, 2 Gen Purpose, 3 Alarm |
| Enclosure Rating | IP20 |
Frequently Asked Questions | |
| What I/O option cards are compatible with the FRN020F1S-2U? The FRN020F1S-2U can be used with the OPC-F1-RY or OPC-115V option cards. | |
| What communication options are available for the FRN020F1S-2U? The FRN020F1S-2U can be used with optional DeviceNet, Modbus RTU, Profibus, CC-Link, and Ethernet option cards. | |
| How much does the FRN020F1S-2U weigh? The FRN020F1S-2U weighs approximately 9.7 kilograms, or 21 pounds. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
If you are operating a 200V fan and pump system, the FRN020F1S-2U is one of the most efficient inverters available. This model still has a high horsepower rating while maintaining relatively low power loss during operation. -Automation Industrial Quality Assurance Manager |
|
