- Unit Name: DS200SPCBG1A
- Manufacturer: General Electric
- Product Line: DC2000 Adjustable Speed Drives
- Part Type: Signal Processing Board
- Version: Multi-Bridge
- Encoder Follower Circuits: 2
- Process Control Circuits: 2
- Differential Interface: 3-Channel
- Analog Input (Current): 1-5mA, 4-20mA, 10-50mA
- Analog Input (Voltage): 2-30V, -5V to 5V
- Board Manual: GEI-100166
- DC2000 Manual: GEH-6005
-
How far can the potentiometers on the DS200SPCBG1A be adjusted?
- These have a working range of 120°.
-
What is the default position of the potentiometers on the DS200SPCBG1A?
- The default position for these potentiometers is straight-up.
-
What kind of decoding does the DS200SPCBG1A use for the encoder inputs?
- The DS200SPCBG1A uses programmable array logic decoding.
⭐⭐⭐⭐⭐ 5.0
Not only does the DS200SPCBG1A have all the necessary hardware to interconnect your multi-bridge comms hub with your drive, but it is also user-configurable for improved performance. This configuration is also easy to do via simple potentiometers, switches, and jumpers. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DS200SPCBG1A Mark V DS200 |
Description |
GE DS200SPCBG1A DS200SPCBG1AAA Multi-Bridge Signal Processing Board Mark V |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Unit Name | DS200SPCBG1A |
| Manufacturer | General Electric |
| Product Line | DC2000 Adjustable Speed Drives |
| Part Type | Signal Processing Board |
| Version | Multi-Bridge |
| Encoder Follower Circuits | 2 |
| Process Control Circuits | 2 |
| Differential Interface | 3-Channel |
| Analog Input (Current) | 1-5mA, 4-20mA, 10-50mA |
| Analog Input (Voltage) | 2-30V, -5V to 5V |
| Board Manual | GEI-100166 |
| DC2000 Manual | GEH-6005 |
Frequently Asked Questions | |
| How far can the potentiometers on the DS200SPCBG1A be adjusted? These have a working range of 120°. | |
| What is the default position of the potentiometers on the DS200SPCBG1A? The default position for these potentiometers is straight-up. | |
| What kind of decoding does the DS200SPCBG1A use for the encoder inputs? The DS200SPCBG1A uses programmable array logic decoding. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
Not only does the DS200SPCBG1A have all the necessary hardware to interconnect your multi-bridge comms hub with your drive, but it is also user-configurable for improved performance. This configuration is also easy to do via simple potentiometers, switches, and jumpers. -Automation Industrial Quality Assurance Manager |
|
