- Unit Number: DS215UCVBG3A
- Equipment Manufacturer: General Electric
- Family Name: Mark V
- Subseries: UC2000V
- Designation: UC2000V Module
- Version: G3
- Required Slots: 4
- Processor: 586-133 Pentium
- DLAN+ Ports: 2
- Genius LAN Ports: 2
- Ethernet Ports: 2
- Manual: GEH-6371
-
Do all the VME slots for the DS215UCVBG3A need to have a P1 connector?
- Yes, except for the third slot (counting from the left).
-
How much memory does the DS215UCVBG3A have?
- The DS215UCVBG3A has 16M DRAM and 4M Flash memory.
-
What kind of Ethernet ports does the DS215UCVBG3A use?
- The DS215UCVBG3A uses 10Base2 Ethernet ports.
⭐⭐⭐⭐⭐ 5.0
The DS215UCVBG3A takes up twice as many slots as a standard UC2000V module, but it also offers twice the number of communications ports. This number of ports is doubled for all of the Ethernet, DLAN+, and Genius LAN networks, making this an excellent choice in larger setups. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
DS215UCVBG3A |
Description |
GE DS215UCVBG3A DS215UCVBG3AF Module Genius Controller Mark V OPEN BOX |
Condition |
New Surplus Open Box Factory Packaged. With 1 Year Warranty |
Technical Specifications | |
| Unit Number | DS215UCVBG3A |
| Equipment Manufacturer | General Electric |
| Family Name | Mark V |
| Subseries | UC2000V |
| Designation | UC2000V Module |
| Version | G3 |
| Required Slots | 4 |
| Processor | 586-133 Pentium |
| DLAN+ Ports | 2 |
| Genius LAN Ports | 2 |
| Ethernet Ports | 2 |
| Manual | GEH-6371 |
Frequently Asked Questions | |
| Do all the VME slots for the DS215UCVBG3A need to have a P1 connector? Yes, except for the third slot (counting from the left). | |
| How much memory does the DS215UCVBG3A have? The DS215UCVBG3A has 16M DRAM and 4M Flash memory. | |
| What kind of Ethernet ports does the DS215UCVBG3A use? The DS215UCVBG3A uses 10Base2 Ethernet ports. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The DS215UCVBG3A takes up twice as many slots as a standard UC2000V module, but it also offers twice the number of communications ports. This number of ports is doubled for all of the Ethernet, DLAN+, and Genius LAN networks, making this an excellent choice in larger setups. -Automation Industrial Quality Assurance Manager |
|
