- Product Name: IS230TBTCH1B
- Original Equipment Manufacturer: GE
- Part Series: Mark VI/Mark VIe Controls
- 5: Thermocouple Input Terminal Board
- Thermocouple Inputs: 24
- Thermocouple Type: E, J, K, S, T
- Redundancy: TMR
- DC-Type Connectors: 6
- Shield Bar: Yes
- Pluggable Terminals: Yes
- Functional Revision: B
- Manual: GEH-6721
-
What I/O pack is supported by the IS230TBTCH1B in Mark VIe applications?
- The IS230TBTCH1B is used with the PTCC I/O pack in Mark VIe applications.
-
Can the IS230TBTCH1B support B, N, or R thermocouple inputs?
- Yes, but only if it is used with the PTCCH2 Mark VIe module.
-
What is different between a IS230TBTCH1B and a IS230TBTCH1C?
- The IS230TBTCH1C is made for simplex applications, while the IS230TBTCH1B is made for TMR.
⭐⭐⭐⭐⭐ 5.0
The IS230TBTCH1B can be used in larger systems with more thermocouple inputs than the H1C version. This board supports a wide range of different thermocouple types as well, offering excellent overall compatibility. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IS230TBTCH1 Mark VI IS230 |
Description |
GE General Electric IS230TBTCH1 IS230TBTCH1B Thermocouple board Mark VI NO BOX |
Condition |
New Surplus Open Box Factory Packaged. With 1 Year Warranty. |
Technical Specifications | |
| Product Name | IS230TBTCH1B |
| Original Equipment Manufacturer | GE |
| Part Series | Mark VI/Mark VIe Controls |
| 5 | Thermocouple Input Terminal Board |
| Thermocouple Inputs | 24 |
| Thermocouple Type | E, J, K, S, T |
| Redundancy | TMR |
| DC-Type Connectors | 6 |
| Shield Bar | Yes |
| Pluggable Terminals | Yes |
| Functional Revision | B |
| Manual | GEH-6721 |
Frequently Asked Questions | |
| What I/O pack is supported by the IS230TBTCH1B in Mark VIe applications? The IS230TBTCH1B is used with the PTCC I/O pack in Mark VIe applications. | |
| Can the IS230TBTCH1B support B, N, or R thermocouple inputs? Yes, but only if it is used with the PTCCH2 Mark VIe module. | |
| What is different between a IS230TBTCH1B and a IS230TBTCH1C? The IS230TBTCH1C is made for simplex applications, while the IS230TBTCH1B is made for TMR. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The IS230TBTCH1B can be used in larger systems with more thermocouple inputs than the H1C version. This board supports a wide range of different thermocouple types as well, offering excellent overall compatibility. -Automation Industrial Quality Assurance Manager |
|
