- Part Number: 469-P5-HI-A20-D
- Series: 469 MMR
- 469 Sensor Supply Digital Inputs: +24 VDC at 20 mA max
- Acceleration Timer Elements: Trip
- Ambient Temperature: –40°C to +60°C
- Humidity: 95% non-condensing
- Phase Short Circuit Pickup Level: 4.0 to 20.0 × CT primary in steps of 0.1 of any one phase
- RTD Time Delay: 3 s
- Static: IEC 801-2 Static Discharge
- Undercurrent Block from Start: 0 to 15000 s in steps of 1
- Voltage Type: High Voltage
-
What options does the 469-P5-HI-A20-D have installed?
- The 469-P5-HI-A20-D features a DeviceNet Option along with an Enhanced Display
-
Does this model still come with the standard RS232 and 2 RS485 ports?
- No, the DeviceNet option takes the place of one of the RS485 ports, leaving this model with 1 RS232 and 1 RS485 port.
⭐⭐⭐⭐⭐ 5.0
Because not many were manufactured, the 469-P5-HI-A20-D is a highly sought after relay. The inclusion of a devicenet option card on the rear part of the 469-P5-HI-A20-D give it additional capability not available on the baseline 469-P5-HI-A20-E model - Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
469-P5-HI-A20-D 469 Motor Management Relay |
Description |
GE Multilin 469-P5-HI-A20-D Motor Management Relay |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Part Number | 469-P5-HI-A20-D |
| Series | 469 MMR |
| 469 Sensor Supply Digital Inputs | +24 VDC at 20 mA max |
| Acceleration Timer Elements | Trip |
| Ambient Temperature | –40°C to +60°C |
| Humidity | 95% non-condensing |
| Phase Short Circuit Pickup Level | 4.0 to 20.0 × CT primary in steps of 0.1 of any one phase |
| RTD Time Delay | 3 s |
| Static | IEC 801-2 Static Discharge |
| Undercurrent Block from Start | 0 to 15000 s in steps of 1 |
| Voltage Type | High Voltage |
Frequently Asked Questions | |
| What options does the 469-P5-HI-A20-D have installed? The 469-P5-HI-A20-D features a DeviceNet Option along with an Enhanced Display | |
| Does this model still come with the standard RS232 and 2 RS485 ports? No, the DeviceNet option takes the place of one of the RS485 ports, leaving this model with 1 RS232 and 1 RS485 port. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
Because not many were manufactured, the 469-P5-HI-A20-D is a highly sought after relay. The inclusion of a devicenet option card on the rear part of the 469-P5-HI-A20-D give it additional capability not available on the baseline 469-P5-HI-A20-E model - Automation Industrial Quality Assurance Manager |
|
