- Model ID: 6KM$243001N1A1
- Produced By: GE Fuji Electric
- Series Name: AF-300 Micro-$aver II
- Product Role: AC Drive
- Voltage Type: 480VAC
- Input Phase: 3-Phase
- Rated Horsepower: 1HP
- Output Voltage: 160-480VAC
- Output Frequency: 0.2-400Hz
- Cooling Type: Natural Convection
- Weight: 4.2lbs
- Manual: GEI-100272
-
What carrier frequencies can be used on the 6KM$243001N1A1?
- The 6KM$243001N1A1 can support frequencies from 0.75kHz to 15kHz.
-
How efficient is this 6KM$243001N1A1 under low/high frequencies?
- This drive is 86.9% efficient under low frequency settings, or 80% efficient under high frequency.
-
What level of voltage variance can the 6KM$243001N1A1 handle?
- The input voltage for the 6KM$243001N1A1 can vary +10% to -15% and remain in acceptable limits.
⭐⭐⭐⭐ 4.0
While the 6KM$243001N1A1 is less protected against environmental threats than its NEMA 4 rated counterpart, this model offers several advantages that can make it a better long-term option in most applications. Primarily, there is a wider range of parts available for these drives and it is easier to access the internal components of this unit in case it needs repairs. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
6KM$243001N1A1 AF-300 Micro-Saver ii |
Description |
General Electric GE Fuji 6KM$243001N1A1 6KMS243001N1A1 1HP AC Drive |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model ID | 6KM$243001N1A1 |
| Produced By | GE Fuji Electric |
| Series Name | AF-300 Micro-$aver II |
| Product Role | AC Drive |
| Voltage Type | 480VAC |
| Input Phase | 3-Phase |
| Rated Horsepower | 1HP |
| Output Voltage | 160-480VAC |
| Output Frequency | 0.2-400Hz |
| Cooling Type | Natural Convection |
| Weight | 4.2lbs |
| Manual | GEI-100272 |
Frequently Asked Questions | |
| What carrier frequencies can be used on the 6KM$243001N1A1? The 6KM$243001N1A1 can support frequencies from 0.75kHz to 15kHz. | |
| How efficient is this 6KM$243001N1A1 under low/high frequencies? This drive is 86.9% efficient under low frequency settings, or 80% efficient under high frequency. | |
| What level of voltage variance can the 6KM$243001N1A1 handle? The input voltage for the 6KM$243001N1A1 can vary +10% to -15% and remain in acceptable limits. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
While the 6KM$243001N1A1 is less protected against environmental threats than its NEMA 4 rated counterpart, this model offers several advantages that can make it a better long-term option in most applications. Primarily, there is a wider range of parts available for these drives and it is easier to access the internal components of this unit in case it needs repairs. -Automation Industrial Quality Assurance Manager |
|
