- Product Name: H4-CTRIO
- Produced By: Host Automation
- Unit Series: DirectLOGIC 405
- Model Type: High-Speed Counter I/O Module
- Inputs: 8
- Sink/Source: Both
- Max Frequency: 100kHz
- Minimum Pulse Width: 5µs
- Pulse Outputs: 2
- Control Range: 20Hz to 25kHz
- Discrete Outputs: 4
- Manual ID: HX-CTRIO-M
-
What voltages can the inputs of the H4-CTRIO operate on?
- These inputs are rated for 9-30VDC.
-
What voltages are the outputs on the H4-CTRIO rated for?
- These outputs are rated for 5-36VDC.
-
Are the output points independently isolated on the H4-CTRIO?
- Yes, these points are isolated.
⭐⭐⭐⭐⭐ 5.0
The H4-CTRIO is the only counter I/O module made for the DirectLOGIC 405 series from Host Automation. This module has several versatile input/output channels which can be used in either sink or source roles as well as a pair of easily adjustable pulse outputs. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
H4-CTRIO DirectLogic 405 |
Description |
H4-CTRIO by Host Automation Pulse Combo Module DL405 DirectLOGIC 405 |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty |
Technical Specifications | |
| Product Name | H4-CTRIO |
| Produced By | Host Automation |
| Unit Series | DirectLOGIC 405 |
| Model Type | High-Speed Counter I/O Module |
| Inputs | 8 |
| Sink/Source | Both |
| Max Frequency | 100kHz |
| Minimum Pulse Width | 5µs |
| Pulse Outputs | 2 |
| Control Range | 20Hz to 25kHz |
| Discrete Outputs | 4 |
| Manual ID | HX-CTRIO-M |
Frequently Asked Questions | |
| What voltages can the inputs of the H4-CTRIO operate on? These inputs are rated for 9-30VDC. | |
| What voltages are the outputs on the H4-CTRIO rated for? These outputs are rated for 5-36VDC. | |
| Are the output points independently isolated on the H4-CTRIO? Yes, these points are isolated. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The H4-CTRIO is the only counter I/O module made for the DirectLOGIC 405 series from Host Automation. This module has several versatile input/output channels which can be used in either sink or source roles as well as a pair of easily adjustable pulse outputs. -Automation Industrial Quality Assurance Manager |
|
