- Unit ID: HE800DQM902
- Manufactured By: Horner Electric
- Model Line: SmartStack Modules
- Description: Relay Output Module
- Outputs: 20
- Max Load Voltage: 250VAC, 30VDC
- Max Load Current: 2.5A
- Output Points Required: 24
- Commons: 5
- Coil Voltage: 20-28VDC
- Isolation: 500VDC
- Product Manual: MAN0371-05
-
Are the outputs on the HE800DQM902 normally open or closed?
- These outputs are normally open.
-
What is the response time like on the HE800DQM902?
- The HE800DQM902 has a 10ms response time in both ON to OFF and OFF to ON cases.
-
How much inrush current is the HE800DQM902 rated for?
- The HE800DQM902 is rated for up to 3A of inrush current.
⭐⭐⭐⭐ 4.0
The HE800DQM902 fits 20 relay outputs into one compact module. This model is compatible with all kinds of operator control systems and is super easy to replace if you experience any sort of failure. Do note that this module does not come with the plastic case option. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
HE800DQM902 HE800 |
Description |
HE800DQM902 By Horner Electric HE800DQM902A 2.5amp 250VAC 20 Relay Output Module |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Unit ID | HE800DQM902 |
| Manufactured By | Horner Electric |
| Model Line | SmartStack Modules |
| Description | Relay Output Module |
| Outputs | 20 |
| Max Load Voltage | 250VAC, 30VDC |
| Max Load Current | 2.5A |
| Output Points Required | 24 |
| Commons | 5 |
| Coil Voltage | 20-28VDC |
| Isolation | 500VDC |
| Product Manual | MAN0371-05 |
Frequently Asked Questions | |
| Are the outputs on the HE800DQM902 normally open or closed? These outputs are normally open. | |
| What is the response time like on the HE800DQM902? The HE800DQM902 has a 10ms response time in both ON to OFF and OFF to ON cases. | |
| How much inrush current is the HE800DQM902 rated for? The HE800DQM902 is rated for up to 3A of inrush current. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The HE800DQM902 fits 20 relay outputs into one compact module. This model is compatible with all kinds of operator control systems and is super easy to replace if you experience any sort of failure. Do note that this module does not come with the plastic case option. -Automation Industrial Quality Assurance Manager |
|
