- Product Name: I2200AC-OP
- Original Manufacturer: Schneider Electric
- Unit Series: Infilink 200
- Part Type: Electronic Repeater
- RS-485 Ports: 5
- Voltage Rating: 115/230VAC
- Enclosure Type: Open
- Input Type: Infinet RS-485
- Outputs: 4
- Power Consumption: 6VA
- Power Input: 3-Pos Barrier Strip
- Operating Temperature: 0° to 49°C
-
How is the input voltage configured on the I2200AC-OP?
- This is switch-selectable on the I2200AC-OP.
-
What kind of cable is acceptable for the ports on the I2200AC-OP?
- The I2200AC-OP is made to use twisted pair cabling.
-
What is the range of each RS-485 output on the I2200AC-OP?
- These have a standard 4000 foot range.
⭐⭐⭐⭐ 4.0
The lack of an enclosure on the I2200AC-OP does make it very easy to access the underlying board components for maintenance, but it does also limit potential mounting locations pretty substantially. If you plan on installing this repeater in an environment without regular exposure to hazards, it should do fine. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
I2200AC-OP Andover Continuum |
Description |
I2200AC-OP By Schneider Electric 05-1001-115 Electronic Infinet Repeater Open |
Condition |
New Surplus Open Box Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Product Name | I2200AC-OP |
| Original Manufacturer | Schneider Electric |
| Unit Series | Infilink 200 |
| Part Type | Electronic Repeater |
| RS-485 Ports | 5 |
| Voltage Rating | 115/230VAC |
| Enclosure Type | Open |
| Input Type | Infinet RS-485 |
| Outputs | 4 |
| Power Consumption | 6VA |
| Power Input | 3-Pos Barrier Strip |
| Operating Temperature | 0° to 49°C |
Frequently Asked Questions | |
| How is the input voltage configured on the I2200AC-OP? This is switch-selectable on the I2200AC-OP. | |
| What kind of cable is acceptable for the ports on the I2200AC-OP? The I2200AC-OP is made to use twisted pair cabling. | |
| What is the range of each RS-485 output on the I2200AC-OP? These have a standard 4000 foot range. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The lack of an enclosure on the I2200AC-OP does make it very easy to access the underlying board components for maintenance, but it does also limit potential mounting locations pretty substantially. If you plan on installing this repeater in an environment without regular exposure to hazards, it should do fine. -Automation Industrial Quality Assurance Manager |
|
