- Model Code: IC300OCS100
- Original Manufacturer: GE Fanuc
- Product Line: IC300 Operator Control Stations
- Primary Power Range: 10-30VDC
- User Keys: 17
- Serial Communications: 9-Pin, RS-232
- CAN Network: CsCAN
- Display: 2x20 LCD
- NEMA Rating: 4-12
- Operating Temperature: -10° to 60°C
- Acceptable Humidity: 5% to 95% (Non-Condensing)
- Manual Name: GFK-1772
-
Is the IC300OCS100 compatible with the SmartStack modules?
- Yes, the IC300OCS100 was made to be used alongside SmartStack modules.
-
How many SmartStack modules can the IC300OCS100 support?
- The IC300OCS100 can support up to 4 of these modules at a time.
-
Is the display on the IC300OCS100 backlit?
- Yes, this model has a backlit display.
⭐⭐⭐⭐ 4.0
The IC300OCS100 is the basic version of local operator control system in the OCS line from GE. The smaller display and lack of a full keypad can make complex operation slightly more difficult compared to the larger models, but this is a great interface for simpler applications. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IC300OCS100 IC300 OCS |
Description |
IC300OCS100 By GE IC300OCS100M 24VDC LCD Display Operator Control Panel |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Model Code | IC300OCS100 |
| Original Manufacturer | GE Fanuc |
| Product Line | IC300 Operator Control Stations |
| Primary Power Range | 10-30VDC |
| User Keys | 17 |
| Serial Communications | 9-Pin, RS-232 |
| CAN Network | CsCAN |
| Display | 2x20 LCD |
| NEMA Rating | 4-12 |
| Operating Temperature | -10° to 60°C |
| Acceptable Humidity | 5% to 95% (Non-Condensing) |
| Manual Name | GFK-1772 |
Frequently Asked Questions | |
| Is the IC300OCS100 compatible with the SmartStack modules? Yes, the IC300OCS100 was made to be used alongside SmartStack modules. | |
| How many SmartStack modules can the IC300OCS100 support? The IC300OCS100 can support up to 4 of these modules at a time. | |
| Is the display on the IC300OCS100 backlit? Yes, this model has a backlit display. | |
Internal Review | |
|
⭐⭐⭐⭐
4.0
The IC300OCS100 is the basic version of local operator control system in the OCS line from GE. The smaller display and lack of a full keypad can make complex operation slightly more difficult compared to the larger models, but this is a great interface for simpler applications. -Automation Industrial Quality Assurance Manager |
|
