- Model Number: IS200EXHSG4A
- Manufacturer: GE
- Series: EX2100
- Role: Exciter High-Speed Relay Driver
- Group: G4
- Control Mode: Breaker Mode
- Redundancy: Simplex
- Trip Relay 41T: Used
- Close Relay 41: Used
- Contact Input: 3
- Wetting Voltage: 70VDC
- Manual: GEI-100475
-
Which contacts are wetted by the IS200EXHSG4A?
- The IS200EXHSG4A wets the 41, 53A, and 53B contacts.
-
What is the redundant equivalent to the IS200EXHSG4A?
- For a redundant equivalent of the IS200EXHSG4A, replace the "G4" in the part number with "G3".
-
Is the IS200EXHSG4A responsible for field flashing/protection?
- Yes, this board is responsible for these functions.
⭐⭐⭐⭐⭐ 5.0
The IS200EXHSG4A is the relay driver board of choice for operators with a simplex, breaker mode type application. This model is especially great in that it supports both the trip and close relay functionalities, which is not found in the contactor versions of this board. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IS200EXHSG4A Mark VI IS200 |
Description |
IS200EXHSG4A By General Electric IS200EXHSG4AEC Exciter Terminal Board NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Model Number | IS200EXHSG4A |
| Manufacturer | GE |
| Series | EX2100 |
| Role | Exciter High-Speed Relay Driver |
| Group | G4 |
| Control Mode | Breaker Mode |
| Redundancy | Simplex |
| Trip Relay 41T | Used |
| Close Relay 41 | Used |
| Contact Input | 3 |
| Wetting Voltage | 70VDC |
| Manual | GEI-100475 |
Frequently Asked Questions | |
| Which contacts are wetted by the IS200EXHSG4A? The IS200EXHSG4A wets the 41, 53A, and 53B contacts. | |
| What is the redundant equivalent to the IS200EXHSG4A? For a redundant equivalent of the IS200EXHSG4A, replace the "G4" in the part number with "G3". | |
| Is the IS200EXHSG4A responsible for field flashing/protection? Yes, this board is responsible for these functions. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The IS200EXHSG4A is the relay driver board of choice for operators with a simplex, breaker mode type application. This model is especially great in that it supports both the trip and close relay functionalities, which is not found in the contactor versions of this board. -Automation Industrial Quality Assurance Manager |
|
