- Part Code: IS200SCLTH1A
- OEM: GE
- Associated Series: Mark VIe
- Board Description: Core Analog Terminal Board
- Fanned Thermocouples: 8
- Thermocouple Types: E, J, K, S, T
- Fanned Analog Inputs: 4
- TMR Analog Inputs: 6
- Commons: 1
- Control Mode: Simplex or TMR
- Dimensions: 6.25" x 7.00"
- Manual ID: GEH-6721L
-
What kind of analog inputs are supported on the IS200SCLTH1A?
- The IS200SCLTH1A supports 4-20mA, ±10V, and ±5V inputs.
-
How far away can the analog voltage/current inputs be from the IS200SCLTH1A?
- These inputs can be up to 300m away from the IS200SCLTH1A.
-
Does the IS200SCLTH1A have any fault detection?
- Yes, the IS200SCLTH1A can detect an incorrect ID chip fault.
⭐⭐⭐⭐⭐ 5.0
The IS200SCLTH1A supports a large amount of fanned thermocouple and analog input signals for the PCLA module. The Euro-style box terminals are easy to wire and are pluggable for easy maintenance. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IS200SCLTH1A Mark VI IS200 |
Description |
IS200SCLTH1A By General Electric IS200SCLTH1AAB Core Analog Terminal Board NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty |
Technical Specifications | |
| Part Code | IS200SCLTH1A |
| OEM | GE |
| Associated Series | Mark VIe |
| Board Description | Core Analog Terminal Board |
| Fanned Thermocouples | 8 |
| Thermocouple Types | E, J, K, S, T |
| Fanned Analog Inputs | 4 |
| TMR Analog Inputs | 6 |
| Commons | 1 |
| Control Mode | Simplex or TMR |
| Dimensions | 6.25" x 7.00" |
| Manual ID | GEH-6721L |
Frequently Asked Questions | |
| What kind of analog inputs are supported on the IS200SCLTH1A? The IS200SCLTH1A supports 4-20mA, ±10V, and ±5V inputs. | |
| How far away can the analog voltage/current inputs be from the IS200SCLTH1A? These inputs can be up to 300m away from the IS200SCLTH1A. | |
| Does the IS200SCLTH1A have any fault detection? Yes, the IS200SCLTH1A can detect an incorrect ID chip fault. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The IS200SCLTH1A supports a large amount of fanned thermocouple and analog input signals for the PCLA module. The Euro-style box terminals are easy to wire and are pluggable for easy maintenance. -Automation Industrial Quality Assurance Manager |
|
