- Model Number: IS420UCSCH1A
- Product Type: UCSE Profinet Stand-Alone Controller
- Manufacturer: GE Vernova
- Product Line: Mark VIe UCSE
- Processor: AMD GX-412HC GE412GHCJ44JB
- CPU Frequency: 1.2 Ghz
- CPU Cores: Qty 4
- L2 Cache: 2 M
- QNX Version: 6.5 or 7.1
- Profinet Capability: Yes
- Total Ethernet Ports: Qty 6
- Console: RJ-45
- Additional Ports: Qty 2 USB 2.0
- Orientation: Vertical
- Max Power Consumption: 31 W
- Minimum Voltage: 18 V
- Nominal Voltage: 24/28 V
- Maximum Voltage: 30 V
- Memory Type: DDR3-1333
- Memory Size: 4 GB
- ECC Memory Capability: Yes
- Flash Storage: 40 GB SSD pSLC (16 GB used)
- NVRAM Capabilities: ControlST V07.05 and higher supports 6139 non-volatile program variables, 338 forces,and 128 totalizers
- Chassis Dimensions: 55mm (width) x 150mm (depth) x 168mm (height)
- Cooling Type: Convection Cooling
- Weight: 46.8 ox or 1327 grams
- Reverse Polarity Protection: Included
- Country of Manufacture/Origin: Assembled in the USA
- Condition: New in Factory Package
- Shipping Time: Ships Same Day
-
Is the RJ-45 adaptor needed for the IS420UCSCH1A included in the purchase?
- The RJ-45 adapter used in conjunction with the IS420UCSCH1A is sold separately. Please inquire for availability.
-
How many of the six ethernet ports on the IS420UCSCH1A are 100 MB ports?
- All six ethernet ports on the IS420UCSCH1A have 100 MB capacity.
⭐⭐⭐⭐⭐ 5.0
The IS420UCSCH1A stand-alone Mark VIe controller is preferable in certain ways to the UCSE controller in that is has profinet capability that the other model does not. Additionally the GX-412HC processor built into the unit provide for different functionality in the application as compared to the UCSE model. As a result of these features, we rate this IS420UCSCH1A as a 5 star product from GE Vernova. - Automation Industrial Lead Technician
Description
General Information about the Product | |
Part Number |
IS420UCSCH1A Mark VIe & Mark VIeS Control Systems |
Description |
IS420UCSCH1A By General Electric UCSC 4C Turbine FA Profinet Controller NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Model Number | IS420UCSCH1A |
| Product Type | UCSE Profinet Stand-Alone Controller |
| Manufacturer | GE Vernova |
| Product Line | Mark VIe UCSE |
| Processor | AMD GX-412HC GE412GHCJ44JB |
| CPU Frequency | 1.2 Ghz |
| CPU Cores | Qty 4 |
| L2 Cache | 2 M |
| QNX Version | 6.5 or 7.1 |
| Profinet Capability | Yes |
| Total Ethernet Ports | Qty 6 |
| Console | RJ-45 |
| Additional Ports | Qty 2 USB 2.0 |
| Orientation | Vertical |
| Max Power Consumption | 31 W |
| Minimum Voltage | 18 V |
| Nominal Voltage | 24/28 V |
| Maximum Voltage | 30 V |
| Memory Type | DDR3-1333 |
| Memory Size | 4 GB |
| ECC Memory Capability | Yes |
| Flash Storage | 40 GB SSD pSLC (16 GB used) |
| NVRAM Capabilities | ControlST V07.05 and higher supports 6139 non-volatile program variables, 338 forces,and 128 totalizers |
| Chassis Dimensions | 55mm (width) x 150mm (depth) x 168mm (height) |
| Cooling Type | Convection Cooling |
| Weight | 46.8 ox or 1327 grams |
| Reverse Polarity Protection | Included |
| Country of Manufacture/Origin | Assembled in the USA |
| Condition | New in Factory Package |
| Shipping Time | Ships Same Day |
Frequently Asked Questions | |
| Is the RJ-45 adaptor needed for the IS420UCSCH1A included in the purchase? The RJ-45 adapter used in conjunction with the IS420UCSCH1A is sold separately. Please inquire for availability. | |
| How many of the six ethernet ports on the IS420UCSCH1A are 100 MB ports? All six ethernet ports on the IS420UCSCH1A have 100 MB capacity. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The IS420UCSCH1A stand-alone Mark VIe controller is preferable in certain ways to the UCSE controller in that is has profinet capability that the other model does not. Additionally the GX-412HC processor built into the unit provide for different functionality in the application as compared to the UCSE model. As a result of these features, we rate this IS420UCSCH1A as a 5 star product from GE Vernova. - Automation Industrial Lead Technician |
|
