- Unit ID: IS7200-01
- Produced By: Cognex Vision
- Associated Series: In-Sight 7000
- Model Description: Industrial Camera/Vision System
- Sensor: 1/1.8-Inch CMOS
- Supported Resolution: 800 by 600
- Minimum Firmware: 4.9.0
- Supported Lens Types: M12 or C-mount
- PatMax: No
- Weight: 220g
- Mounting: 4xM3
- Manual Name: In-Sight 7000 Series Vision System Reference Guide
-
What bit depth is supported on the IS7200-01?
- The IS7200-01 supports the standard 256 gray levels as other monochrome In-Sight vision systems.
-
How protected are the internal components of the IS7200-01?
- The housing of this unit protects at an IP67 level when the lens cover is installed.
-
What are the dimensions of the IS7200-01?
- With an M12 type lens installed, this model is approximately 55mm by 84.8mm by 55mm; with a C-mount lens (and cover) installed, this changes to 75mm by 83mm by 84.8mm.
⭐⭐⭐⭐ 4.0
The IS7200-01 is one of the first-generation In-Sight 7000 vision systems, which comes with slightly lower performance than the newer models. This is still relatively advanced for an In-Sight system, but it is not the highest level when it comes to longevity and raw power. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IS7200-01 In-Sight 7000 |
Description |
IS7200-01 By Cognex 825-0519-1R A In-Sight 7000 Series Vison System |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty. |
Technical Specifications | |
Unit ID | IS7200-01 |
Produced By | Cognex Vision |
Associated Series | In-Sight 7000 |
Model Description | Industrial Camera/Vision System |
Sensor | 1/1.8-Inch CMOS |
Supported Resolution | 800 by 600 |
Minimum Firmware | 4.9.0 |
Supported Lens Types | M12 or C-mount |
PatMax | No |
Weight | 220g |
Mounting | 4xM3 |
Manual Name | In-Sight 7000 Series Vision System Reference Guide |
Frequently Asked Questions | |
What bit depth is supported on the IS7200-01? The IS7200-01 supports the standard 256 gray levels as other monochrome In-Sight vision systems. | |
How protected are the internal components of the IS7200-01? The housing of this unit protects at an IP67 level when the lens cover is installed. | |
What are the dimensions of the IS7200-01? With an M12 type lens installed, this model is approximately 55mm by 84.8mm by 55mm; with a C-mount lens (and cover) installed, this changes to 75mm by 83mm by 84.8mm. | |
Internal Review | |
⭐⭐⭐⭐
4.0
The IS7200-01 is one of the first-generation In-Sight 7000 vision systems, which comes with slightly lower performance than the newer models. This is still relatively advanced for an In-Sight system, but it is not the highest level when it comes to longevity and raw power. -Automation Industrial Quality Assurance Manager |
