- Product Code: IS7402-11
- Original Equipment Manufacturer: Cognex
- Unit Series: In-Sight 7000
- Role: Vision System
- Model Version: 11
- PatMax Included: Yes
- Sensor: 1/1.8" CMOS
- Monochrome/Color: Monochrome
- Image Resolution: 1280x1024 Pixels
- Ambient Operating Temperature: 0° to 45°C
- IP Rating: IP67
- User Manual: In-Sight 7000 Series Vision System Reference Guide
-
Why is the maximum FPS rating of the IS7402-11 lower than the baseline In-Sight 7000 models?
- This is due to the increased resolution on this model.
-
Can I add to the job/program memory on the IS7402-11?
- Yes, you can connect this system to a network device and use its memory for this purpose instead.
-
Can I add to the image processing memory on the IS7402-11?
- No, this is limited to the 256MB of SDRAM that is built into the system.
⭐⭐⭐⭐⭐ 5.0
The IS7402-11 is one of the highest-level models in the first generation of In-Sight 7000 vision systems. Not only does this model have excellent acquisition and sensor ratings, but it also includes the advanced PatMax technology that opens up a much wider range of potential applications through complex pattern-matching. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
IS7402-11 In-Sight 7000 |
Description |
IS7402-11 By Cognex 825-0351-1R A 24VDC Vision System Camera |
Condition |
Pre-Owned Clean and Tested. With 1 Year Warranty |
Technical Specifications | |
Product Code | IS7402-11 |
Original Equipment Manufacturer | Cognex |
Unit Series | In-Sight 7000 |
Role | Vision System |
Model Version | 11 |
PatMax Included | Yes |
Sensor | 1/1.8" CMOS |
Monochrome/Color | Monochrome |
Image Resolution | 1280x1024 Pixels |
Ambient Operating Temperature | 0° to 45°C |
IP Rating | IP67 |
User Manual | In-Sight 7000 Series Vision System Reference Guide |
Frequently Asked Questions | |
Why is the maximum FPS rating of the IS7402-11 lower than the baseline In-Sight 7000 models? This is due to the increased resolution on this model. | |
Can I add to the job/program memory on the IS7402-11? Yes, you can connect this system to a network device and use its memory for this purpose instead. | |
Can I add to the image processing memory on the IS7402-11? No, this is limited to the 256MB of SDRAM that is built into the system. | |
Internal Review | |
⭐⭐⭐⭐⭐
5.0
The IS7402-11 is one of the highest-level models in the first generation of In-Sight 7000 vision systems. Not only does this model have excellent acquisition and sensor ratings, but it also includes the advanced PatMax technology that opens up a much wider range of potential applications through complex pattern-matching. -Automation Industrial Quality Assurance Manager |
