- Part Number: PM820
- OEM: Square D
- Family: PowerLogic
- Subseries: Series 800 Power Meter
- Integrated Display: Yes
- RMS Metering: 31st Harmonic
- Clock Type: Non-Volatile
- CT/PT Input: Supported
- Voltage Input Connection: 600V
- Alarm Logging: Yes
- Current/Voltage Accuracy: 0.075%
- Manual: 63230-500-225A2
-
Is the PM820 the same as a "PM820MG"?
- Yes, the only difference is that the PM820 was made by Square D, while the "PM820MG" was made by Schneider Electric.
-
Can you download firmware directly to the PM820?
- Yes, this is a supported feature of the PM820.
-
Is the PM820 password-protected?
- Yes, the PM820 supports password protection.
⭐⭐⭐⭐⭐ 5.0
The PM820 is not as advanced as the 50 or 70 models of this power meter, but it has a lot of the features from these later models which are not present at all in the base 10 model. These features are not to the same level as in the later versions, but the PM820 can support basic data logging and harmonic metering for example. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
3020-PM820 PowerLogic 3020 |
Description |
PM820 By Square D PowerLogic Class 3020 115-415V Power Meter NSNB |
Condition |
New Surplus Open Box With 1 Year Warranty. |
Technical Specifications | |
| Part Number | PM820 |
| OEM | Square D |
| Family | PowerLogic |
| Subseries | Series 800 Power Meter |
| Integrated Display | Yes |
| RMS Metering | 31st Harmonic |
| Clock Type | Non-Volatile |
| CT/PT Input | Supported |
| Voltage Input Connection | 600V |
| Alarm Logging | Yes |
| Current/Voltage Accuracy | 0.075% |
| Manual | 63230-500-225A2 |
Frequently Asked Questions | |
| Is the PM820 the same as a "PM820MG"? Yes, the only difference is that the PM820 was made by Square D, while the "PM820MG" was made by Schneider Electric. | |
| Can you download firmware directly to the PM820? Yes, this is a supported feature of the PM820. | |
| Is the PM820 password-protected? Yes, the PM820 supports password protection. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The PM820 is not as advanced as the 50 or 70 models of this power meter, but it has a lot of the features from these later models which are not present at all in the base 10 model. These features are not to the same level as in the later versions, but the PM820 can support basic data logging and harmonic metering for example. -Automation Industrial Quality Assurance Manager |
|
