- Model ID: PSC1590V
- Equipment Manufacturer: Maxcess, Magpowr
- Associated Series: Sofstep
- Part Type: Magnetic Particle Clutch
- Voltage: 90VDC
- Current: 0.12A Max
- Power Wires: 2
- Mounting Orientation: Any
- Maximum Storage Temperature: 80°C
- Min RH: 5%
- Max RH: 85%
- Manual: MI 850A226 1 D
-
What temperatures can the PSC1590V operate in?
- The PSC1590V is rated to operate in conditions from 0°C up to 40°C.
-
What is the maximum altitude the PSC1590V can operate at?
- The PSC1590V is rated for use up to 2000 meters.
-
Does the PSC1590V require scheduled maintenance?
- No, the PSC1590V does not require scheduled maintenance.
⭐⭐⭐⭐⭐ 5.0
The PSC1590V is the higher-voltage 90V option of this clutch model. Beyond wiring it into the power supply, installation of this device is relatively quick and flexible, as you can mount it in whatever orientation you please. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
PSC1590V |
Description |
PSC1590V By MagPowr 0.11A 90VDC Magnetic Particle Clutch/Brake NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Model ID | PSC1590V |
| Equipment Manufacturer | Maxcess, Magpowr |
| Associated Series | Sofstep |
| Part Type | Magnetic Particle Clutch |
| Voltage | 90VDC |
| Current | 0.12A Max |
| Power Wires | 2 |
| Mounting Orientation | Any |
| Maximum Storage Temperature | 80°C |
| Min RH | 5% |
| Max RH | 85% |
| Manual | MI 850A226 1 D |
Frequently Asked Questions | |
| What temperatures can the PSC1590V operate in? The PSC1590V is rated to operate in conditions from 0°C up to 40°C. | |
| What is the maximum altitude the PSC1590V can operate at? The PSC1590V is rated for use up to 2000 meters. | |
| Does the PSC1590V require scheduled maintenance? No, the PSC1590V does not require scheduled maintenance. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The PSC1590V is the higher-voltage 90V option of this clutch model. Beyond wiring it into the power supply, installation of this device is relatively quick and flexible, as you can mount it in whatever orientation you please. -Automation Industrial Quality Assurance Manager |
|
