- Product ID: STA/TPRG/3PRG/U-AO-DIN
- Manufacturer Name: Moore
- Part Family: STA TPRG
- Unit Type: Programmable Safety Trip Alarm
- Input Type: RTD, T/C, Ω, mV, Pot
- Output Type: Alarm, Fault Relay
- Alarm Outputs: 2
- Fault Relays: 1
- Power Range: Universal
- Input Voltage Range: 21.6-375VDC, 90-260VAC
- Country of Origin: USA
- Series Manual: 225-748-00S
-
Does the STA/TPRG/3PRG/U-AO-DIN have any optional features?
- Yes, the STA/TPRG/3PRG/U-AO-DIN has the optional 0-20mA/0-10V analog output.
-
Does the STA/TPRG/3PRG/U-AO-DIN have an integral display?
- Yes, this model has an integral display.
-
Can the STA/TPRG/3PRG/U-AO-DIN be used in SIS systems?
- Yes, the STA/TPRG/3PRG/U-AO-DIN is rated for use in SIS systems.
⭐⭐⭐⭐⭐ 5.0
The STA/TPRG/3PRG/U-AO-DIN is one of the most universal versions of these trip alarm devices from Moore. This model can accept a wide variety of different inputs, operates on an extremely broad voltage range of either AC or DC, and can be mounted to standard 35mm DIN rails. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
STA/TPRG/3PRG/U-AO-DIN |
Description |
STA/TPRG/3PRG/U-AO-DIN By Moore 90-260VAC Functional Safety Alarm Trip |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Product ID | STA/TPRG/3PRG/U-AO-DIN |
| Manufacturer Name | Moore |
| Part Family | STA TPRG |
| Unit Type | Programmable Safety Trip Alarm |
| Input Type | RTD, T/C, Ω, mV, Pot |
| Output Type | Alarm, Fault Relay |
| Alarm Outputs | 2 |
| Fault Relays | 1 |
| Power Range | Universal |
| Input Voltage Range | 21.6-375VDC, 90-260VAC |
| Country of Origin | USA |
| Series Manual | 225-748-00S |
Frequently Asked Questions | |
| Does the STA/TPRG/3PRG/U-AO-DIN have any optional features? Yes, the STA/TPRG/3PRG/U-AO-DIN has the optional 0-20mA/0-10V analog output. | |
| Does the STA/TPRG/3PRG/U-AO-DIN have an integral display? Yes, this model has an integral display. | |
| Can the STA/TPRG/3PRG/U-AO-DIN be used in SIS systems? Yes, the STA/TPRG/3PRG/U-AO-DIN is rated for use in SIS systems. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The STA/TPRG/3PRG/U-AO-DIN is one of the most universal versions of these trip alarm devices from Moore. This model can accept a wide variety of different inputs, operates on an extremely broad voltage range of either AC or DC, and can be mounted to standard 35mm DIN rails. -Automation Industrial Quality Assurance Manager |
|
