- Part Number: T1K-16NA-1
- Manufactured By: Automation Direct
- Product Line: Terminator
- Designation: AC Input Module
- Total Inputs: 16
- Commons: 4/Point
- Isolated: Yes
- Input Voltage: 80-132VAC
- Operating Voltage: 90-120VAC
- Frequency Range: 47-63Hz
- Weight: 120g
- Manual ID: T1K-INST-M
-
What kind of certifications does the T1K-16NA-1 have?
- The T1K-16NA-1 has CE, UL, and FCC class A approvals.
-
How much voltage can the T1K-16NA-1 withstand?
- The T1K-16NA-1 can withstand up to 1500VAC for up to a minute.
-
What level of impedance are the inputs on the T1K-16NA-1 rated for?
- Under 50Hz conditions, this value is 14kΩ; at 60Hz, this value is 12kΩ.
⭐⭐⭐⭐⭐ 5.0
The T1K-16NA-1 is a great 16-channel AC input module in the Terminator line from Automation Direct. This model is incredibly power-efficient, drawing significantly less current than most comparable I/O modules. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
T1K-16NA-1 T1K |
Description |
T1K-16NA-1 By Automation Direct 16-Point AC Discrete Input Module |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Part Number | T1K-16NA-1 |
| Manufactured By | Automation Direct |
| Product Line | Terminator |
| Designation | AC Input Module |
| Total Inputs | 16 |
| Commons | 4/Point |
| Isolated | Yes |
| Input Voltage | 80-132VAC |
| Operating Voltage | 90-120VAC |
| Frequency Range | 47-63Hz |
| Weight | 120g |
| Manual ID | T1K-INST-M |
Frequently Asked Questions | |
| What kind of certifications does the T1K-16NA-1 have? The T1K-16NA-1 has CE, UL, and FCC class A approvals. | |
| How much voltage can the T1K-16NA-1 withstand? The T1K-16NA-1 can withstand up to 1500VAC for up to a minute. | |
| What level of impedance are the inputs on the T1K-16NA-1 rated for? Under 50Hz conditions, this value is 14kΩ; at 60Hz, this value is 12kΩ. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The T1K-16NA-1 is a great 16-channel AC input module in the Terminator line from Automation Direct. This model is incredibly power-efficient, drawing significantly less current than most comparable I/O modules. -Automation Industrial Quality Assurance Manager |
|
