- Unit No: XPBD4
- Manufacturer Name: Schneider Electric
- Series: xP Expansion Modules
- Part Type: Combination Expansion Module
- Universal Inputs: 4
- Input Voltage: 0.5-115VDC
- Input Impedance: 10KΩ
- Digital Outputs: 4
- Output Type: 2/4 SPST, Form C
- Output Rating: ≤3A, 24VAC/DC
- Output Override: Yes
- Power Consumption: 125mA
-
Which controllers support the XPBD4?
- The XPBD4 is supported by the bCX1 controller models.
-
What kind of overvoltage protection does the XPBD4 have?
- The XPBD4 has ±1500V transients for both its inputs and outputs.
-
Where does the XPBD4 get its power?
- The XPBD4 draws power directly from the controller.
⭐⭐⭐⭐⭐ 5.0
The XPBD4 is one of the only combination xP modules that provides both input and output channels in the same device. This makes it one of the most space-efficient designs in the series for the controllers it is supported by. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
XPBD4 xP Expansion Modules |
Description |
XPBD4 By Schneider Electric 05-1001-289 Digital Output Expansion Module |
Condition |
Pre-Owned Cleaned and Tested. With 1 Year Warranty. |
Technical Specifications | |
| Unit No | XPBD4 |
| Manufacturer Name | Schneider Electric |
| Series | xP Expansion Modules |
| Part Type | Combination Expansion Module |
| Universal Inputs | 4 |
| Input Voltage | 0.5-115VDC |
| Input Impedance | 10KΩ |
| Digital Outputs | 4 |
| Output Type | 2/4 SPST, Form C |
| Output Rating | ≤3A, 24VAC/DC |
| Output Override | Yes |
| Power Consumption | 125mA |
Frequently Asked Questions | |
| Which controllers support the XPBD4? The XPBD4 is supported by the bCX1 controller models. | |
| What kind of overvoltage protection does the XPBD4 have? The XPBD4 has ±1500V transients for both its inputs and outputs. | |
| Where does the XPBD4 get its power? The XPBD4 draws power directly from the controller. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The XPBD4 is one of the only combination xP modules that provides both input and output channels in the same device. This makes it one of the most space-efficient designs in the series for the controllers it is supported by. -Automation Industrial Quality Assurance Manager |
|
