- Part Number: XPUI4-A
- Brand Name: Schneider Electric
- Associated Series: xP Expansion Modules
- Module Type: Universal Input
- Inputs: 4
- Digital Input: Supported
- Motion Sensor Input: Supported
- Pulse Counter Input: Supported
- Temperature Input: Supported
- Power Consumption: 50mA
- Voltage: 0.5-115VDC
- Impedance: 10KΩ
-
What voltage range are the inputs on the XPUI4-A rated for?
- These inputs are rated for voltages between 0-5VDC.
-
What input power does the XPUI4-A run on?
- The XPUI4-A accepts 24VDC input.
-
What conductor material is acceptable for wiring the XPUI4-A?
- The XPUI4-A is compatible with copper conductors only.
⭐⭐⭐⭐⭐ 5.0
The XPUI4-A is one of the most versatile input modules available for this series, and this one is still in excellent, new condition. Overall, this module is extremely reliable and able to add support for all sort of common inputs to your system. -Automation Industrial Quality Assurance Manager
Description
General Information about the Product | |
Part Number |
XPUI4-A xP Expansion Modules |
Description |
XPUI4-A By General Electric 05-1001-289 4-Universal Input Expansion Module NSFP |
Condition |
New Surplus Factory Package With 1 Year Warranty. |
Technical Specifications | |
| Part Number | XPUI4-A |
| Brand Name | Schneider Electric |
| Associated Series | xP Expansion Modules |
| Module Type | Universal Input |
| Inputs | 4 |
| Digital Input | Supported |
| Motion Sensor Input | Supported |
| Pulse Counter Input | Supported |
| Temperature Input | Supported |
| Power Consumption | 50mA |
| Voltage | 0.5-115VDC |
| Impedance | 10KΩ |
Frequently Asked Questions | |
| What voltage range are the inputs on the XPUI4-A rated for? These inputs are rated for voltages between 0-5VDC. | |
| What input power does the XPUI4-A run on? The XPUI4-A accepts 24VDC input. | |
| What conductor material is acceptable for wiring the XPUI4-A? The XPUI4-A is compatible with copper conductors only. | |
Internal Review | |
|
⭐⭐⭐⭐⭐
5.0
The XPUI4-A is one of the most versatile input modules available for this series, and this one is still in excellent, new condition. Overall, this module is extremely reliable and able to add support for all sort of common inputs to your system. -Automation Industrial Quality Assurance Manager |
|
